Application of Max. 2000*4000mm 1~5 Decks Gyratory Sifter for Granular Graphite Screening Above 90% Accuracy:
The gyratory sifter can be widely used in metallurgical, abrasive, mining, quarrying, chemical, clay, glass, building materials, medicine, food processing, grain, plastics and other industries of fine classification.
This kind of gyratory screening machine can be used for the most demanding screening requirements of silica sand, activated carbon, calcium carbonate, fertilizer, frac sand, plastic particles, polyvinyl chloride powder, limestone, petroleum coke, sugar, salt etc.
Overview of Max. 2000*4000mm 1~5 Decks Gyratory Sifter for Granular Graphite Screening Above 90% Accuracy:
Limestone Rectangular Gyratory Sifteris a new type of high-performance industrial sifting equipment. It does gyratory reciprocating motion. This sifter is designed to provide high throughput rate while ensure cleaner separation.
1. Screens can be replaced from either end of machine
2. Adjust and tension screens from outside sifter
3. Long retention time and accurate separations
4. Higher capacity while cleaner separation
Our 2AFF model gyratory sifter separators can maximize the productivity, provide maximum vibration control and enables maximum recovery of clean and acceptable product. This sieving machine can increase your plant's productivity by reducing the costs associated with routine maintenance and unscheduled repairs. That means fewer production outages and fewer instances of pulling employees away from other duties for unscheduled maintenance. It all adds up to less downtime, larger capacity and lower cost.
The gyratory sifter can be widely used in chemical, metallurgy, food, mineral and other industries for sifting dry materials, such as silica sand, fertilizer, feed, minerals and other bulk solids.
Motion
gyratory reciprocating motion: the material is completely covered with the screen, making full use of the screen
Layers of Screen
1~5 layers (*2)
Duplex Screening
can realize multi-layer double screening with the same mesh
Screen Type
hook-plate screen
Drive Device
exciter + motor + V-belt
Motor Brand
Siemens, ABB etc.
Amplitude
large horizontal amplitude can effectively improve the screening effect of near-size particles
Working Principleof Max. 2000*4000mm 1~5 Decks Gyratory Sifter for Granular Graphite Screening Above 90% Accuracy:
What is AAREAL AF and 2AFF model gyratory sifter? How does the multi-deck gyratory sifter work?
The total gyratory motion of the multi-deck gyratory sifter for silica sand glass sand can rapidly spread, stratify and separate the material. The unique gyratory motion can quickly spread the material across the full width of screen at the feed end, driving the particles move forward contact with the screen surface. The large horizontal amplitude can improve the sieving effect of the near-size particles, and can improve the material processing capacity of the machine.
1. The unique gyratory reciprocating motion makes the whole screen surface of gyratory sifter for petroleum coke have the equivalent screening efficiency, which can realize the large yield and high precision screening.
2. Quick-open type hinged door and rapid screen mesh tension system ensure quick replacement and inspection of screen mesh.
3. The high speed rotation of the exciter improves the acceleration value of the elastic ball, so that the elastic ball impacts screen surface more powerfully. The screen mesh is not easy to plug, prolonging the service life of the screen, reducing the downtime, and ensuring the continuity of screening.
4. The unique suspension system makes the whole machine run smoothly. The sieving machine itself is less destructive. The basic dynamic load is low and the equipment does not need to be fixed.
5. Forward stretch material discharging, easy to collect.
6. Vibration exciter is maintenance-free within 2 years. Adopt high quality lubricating grease, high quality sealing ring and high quality sealing bearing.
7. The dynamic balance drive increases the exciter's rotation speed from 150~180 RPM to 300 RPM.
8. Soft running and low noise.
9. Larger capacity. Duplex screening is available.
10. Fully enclosed structure and dust-free.
11. The movement of the multi-deck gyratory screen separator for activated carbon, the screen mesh protection support design, and the effective cleaning of the elastic ball make the screen service life long.
Quick-open Door Vibration Exciter
Both sides of the screen are tensioned Ball Deck
Technical Parameters of Max. 2000*4000mm 1~5 Decks Gyratory Sifter for Granular Graphite Screening Above 90% Accuracy:
Model
Screen Surface Specifications
Power
(kw)
Amplitude (mm)
Operating Frequency(r/min)
Leaning Angle of Screen (°)
L*W*H (mm)
(Reference)
AF-515
500*1500
2.2
20~60
180~300
4~8
2900*1150*1500
AF-520
500*2000
2900*1150*1900
AF-525
500*2500
3400*1150*1900
AF-1025
1000*2500
3
3400*1700*1950
AF-1030
1000*3000
3900*1700*1950
AF-1036
1000*3600
4500*1700*1950
AF-1530
1500*3000
5.5
3900*2200*1950
AF-1536
1500*3600
4500*2200*1950
AF-1830
1800*3000
7.5
3900*2500*1950
AF-1836
1800*3600
4500*2500*1950
AF-2030
2000*3000
7.5
3900*2700*1950
AF-2036
2000*3600
4500*2700*1950
Note:
All specifications of this series of gyratory screener can be equipped with one to six layers of screen mesh. Under special circumstances, it can be equipped with ten layer screen mesh.
