High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy

High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy

Introduction of High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:

What is the Rotex Gyratory Screening Separator for dolomite? The gyratory screening machine is also called gyratory screen, gyratory screener, gyratory separator, gyratory sifter, gyratory screening machine, Rotex screen, Rotex screening machine, Rotex separator, planar rotary screen, plane rotary screen, rotary flat sieve, flat screen, square precision screening machine, reciprocating screen etc.

   The gyratory screen is mainly designed for large capacity and fine screening needs.

   Our AD model gyratory screen sifter is one of the best seller of our company compare with other kinds of sieving equipments. And the performance of this gyratory screen have been proven by many customers in different industry applications.

Please let me know the following questions in order to recommend you the suitable model for gyratory screener:
1. What kind of raw material you want to process? Does this material have special physical or chemical properties? Such as wet, high temperature, corrosive etc.
2. How many screen decks do you require for the machine?
3. The mesh size of each layer.
4. The voltage and hertz.
5. What kind of material do you prefer for the machine? Carbon steel, or SS304 /316 stainless steel?

Useful Information You Can't Miss About High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:

Advantages of High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:

1. ball cleaning system

2. double-balanced motor system

3. convenient and quick compensating clamps for head cover

4. unique gyratory reciprocating motion

5. automatic screen surface tension device

Performance and Features​ of High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:
1. Lower headroom permits operation in confined areas, reducing cost of building and maintenance.

2. All components are easily accessible and removable for ease of disassembly and cleaning.
3. No vertical vibration, longer life span of mesh (6~12 months).

4. Less conveying equipment is required for elevating material to the feed point.
5. Greater product yields at higher production rates.
6. Low energy consumption.
7. High screening efficiency.
8. Create low noise pollution.
9. Every layer is installed an anti-blocking and cleaning facility and able to clean mesh while sieving.
10. Exterior is designed for easy cleaning. Exterior permanent joints are either welded continuously, or strip welded and filled with epoxy.


Working Principle of High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:

  The gyratory vibrating screen could spreads the material across the full width of the screen surface, the material flow thickness will be thiner than other sifting equipment. The material will be easy to be sifting becasuse thiner the flow bed.

Feeding Port → Round Motion → Elliptic Motion → Linear Motion → Discharge Port

 1. The materials do the reciprocating-gyratory motion along with the gyratory screen running, and there is not vertical jump during the gyratory screen running period, the little size material will go to the bottom of the flow bed along moving forward, the material particle will pass the mesh aperture when the particle size is less than the gyratory sifter aperture size. The reciprocating gyratory motion will make the material flow bed touch the screener mesh surface with longer time for increasing the screening efficiency.


 2. The reciprocating gyratory motion of the Rotex gyratory screener will spread the material flow bed evenly along with the screener mesh bed after material fall into the inlet, the material flow bed will be very thin after being spread, it is good for material screening , and the material screening precision and capacity will be increased.

 3. The screen deck of gyratory screening equipment consist of mesh, spring clamp, ball trays and self-cleaning balls. The self-cleaning balls jump ceaselessly along with gyratory screen operation, the ball could hit the screen mesh in order to let the mesh vibration, so the material blocked in the mesh aperture or adhered to the mesh surface will be cleaned out, it could make sure the aperture ratio so guarantee the screening efficiency.


 4. The gyratory screen do not have vertical vibration, so it do not have much load request on the base foundation, it is much lower than the vibration type screening machine, so the gyratory screener could save steel structure cost, the customer do not need to consider the install load limited.

Technical Parameters of High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:

There are different models of Rotex Type Gyratory Vibrating Screen Sifter for your reference, and we will choose a suitable model according to your specific materials and application.

Application of High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:

Carbon products: coking coal, graphite, charcoal etc.

Chemical products: hundreds of different compounds

Clay: product classification

Abrasive: glass beads, slag, alumina, sand and other abrasive materials

Animal feed: feed powder and chips, meat paste and small food

Fertilizer: raw material sieving and finished product fine screening.

Paper: paper pulp, coating

Fiberboard: wood chips, flaking, bits of wood, to make high quality fiberboard

Drug: many large drug manufacturers use our screening machines, which meet the health standard design and GMP, to achieve precise and effectiveseparation and cleaning

Plastic: plastic particles, plastic powder

Powder metal: aluminum, copper, iron, nickel, steel, zinc and many other metal powders

Recycling of resources: used in the recycling of various materials, such as PET recycling etc.

Steel-making: classification of steel shot and metal filing

Including ammonium nitrate, phosphate, potassium hydroxide, urea and other compounds

Food: sugar, flour, milk powder, coffee, cereals, rice, nuts, condiments, cocoa powder, glucose, starch etc.

Grain cleaning: corn, wheat, soybean and other cereals peeling and cleaning

Ore: ore, rubble, limestone, soda ash and salt

Installation Method of High Efficiency 1~4 Decks 10 TPH Dolomite Rotex Gyratory Screener for Dolomite Screening With 90%~95% High Screening Accuracy:

1. Seat Installation or Floor Mounting:

                      Forward Type                                                Direct Discharge Type

2. Cable Suspension Installation:

                                                        Cable Suspension Type
