High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder

High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder

  • High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder
  • High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder
High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plastic film for the machine body, and plywood wooden case (fumigation-free) for the spare parts such as screens etc.
Delivery Time: 20~35 work days after order confirmed
Payment Terms: T/T, L/C
Supply Ability: 5 sets per month
Contact Now
Detailed Product Description
Features: Multi-layer Screening, High Yield, High Accuracy Material: Carbon Steel, Stainless Steel Etc.
Screening Area: 2.5 M² ~7.2 M² Layers Of Screen: Usually 1~6 Screen Decks (customizable)
Mesh Cleaning System: Bounce Balls (rubber Balls, Silicone Balls Etc.) Motor Brand: Siemens, ABB Etc.
Power: 3KW~7.5KW Application: PVC Powder, Fertilizer, Activated Carbon, Silica Sand, Petroleum Coke Etc.
Highlight:

Polyvinyl Gyratory Screen Separator

,

PVC Powder Gyratory Screen Separator

,

PVC Powder vibratory sieve shaker

High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder



Overview of High Yield Gyratory Screening Separator for Polyvinyl Chloride PVC Powder:

High Yield Gyratory Screening Separator for Polyvinyl Chloride PVC Powder does gyratory reciprocating motion. It is not a vibrating type screener. And the material is completely covered with the screen, making full use of the screen. So it can get large capacity and high screening accuracy. Besides, the screen has a longer service life and is easy to reaplace.



Application of High Yield Gyratory Screening Separator for Polyvinyl Chloride PVC Powder​​​​:

   AAREAL's gyratory screen separator can be widely used in quarrying, clay, glass, building materials, metallurgical, abrasive, mining, chemical, medicine, plastics and other industries for the most demanding screening requirements, such as polyvinyl chloride powder, salt, sugar, petroleum coke, activated carbon, fertilizer, frac sand, limestone, plastic particles etc.



Motion gyratory reciprocating motion: the material is completely covered with the screen, making full use of the screen
Layers of Screen 1~6 layers, even 10 layers under special circumstances
Duplex Screening can realize multi-layer double screening with the same mesh
Screen Type hook screen
Drive Device exciter + motor + belt
Motor Brand Siemens, ABB etc.
Amplitude large horizontal amplitude can effectively improve the screening effect of near-size particles
Mesh Cleaning Method bouncing balls
Application urea, fertilizer, activated carbon, fracturing sand, petroleum proppant, petroleum coke, quartz sand, fertilizer, plastic particles, sugar, salt etc.



Working Principle of High Yield Gyratory Screening Separator for Polyvinyl Chloride PVC Powder:

High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder 0

  The rectangular gyratory sifter separator is also called reciprocating screen, if see from the motion trail of screen box. The vibratory force produced by its driving device is the inertial force twining along the dead axle, the direction of which is change according to a certain regular. The essence of square swinging screen is the reciprocating inertial force formed by the rotation of eccentric wheel winding the dead axle. According to the structure characteristics and working principle of swinging screen, the screen surface is arranged with level or incline (angle of inclination is 0-5 degree). After turn on the swinging screen, the screen box take reciprocating movement under the inertial force, screen box drives screen surface to make periodic shaking, which makes the materials on the screen surface to make directional jumping movement with the screen box. During the period, the material less than the screen aperture falls to under layer, the material bigger than the screen aperture make jumping movement, discharged from the coarse outlet.



High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder 1High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder 2

              Quick-open Access Door                                                Exciter

High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder 3High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder 4

              Tensioned Screens                                                   Ball Decks



Characteristics of High Yield Gyratory Screening Separator for Polyvinyl Chloride PVC Powder:

1. Screen Removal: all screens are designed with the ability to change-out the screens quickly and smoothly.

2. Ball Decks: all screens are equipped with “Ball-Decks” to assist in keeping the screen clean.

3. Tensioned Screen Design: we uses tensioned screens as a standard to prevent the elements from losing their tension over time, as stapled-down elements often do.

4. Cleaning Efficiency and Minimum Product Loss: our drive unit is at the absolute center of the machine, so you get the

same screening motion and efficiency over the entire screen surface.

5. Dynamically Balanced: dynamically balances all screens to minimize building loads.



Technical Parameters of High Yield Gyratory Screening Separator for Polyvinyl Chloride PVC Powder​​​​:

High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder 5

Model Screen Surface Specifications

Power

(kw)

Amplitude (mm) Operating Frequency (r/min) Leaning Angle of Screen (°)

L*W*H (mm)

(Reference)

AF-515 500*1500 2.2 20~60 180~300 4~8 2900*1150*1500
AF-520 500*2000 2900*1150*1900
AF-525 500*2500 3400*1150*1900
AF-1025 1000*2500 3 3400*1700*1950
AF-1030 1000*3000 3900*1700*1950
AF-1036 1000*3600 4500*1700*1950
AF-1530 1500*3000 5.5 3900*2200*1950
AF-1536 1500*3600 4500*2200*1950
AF-1830 1800*3000 7.5 3900*2500*1950
AF-1836 1800*3600 4500*2500*1950
AF-2030 2000*3000 7.5 3900*2700*1950
AF-2036 2000*3600 4500*2700*1950

Note: Our company reserves the right to modify the data above.



High Yield Gyratory Screen Separator For Polyvinyl Chloride PVC Powder 6
