Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment

  • Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment
  • Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment
  • Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment
Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AY
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Other Names: Round Separator, Vibro Sieve, Vibro Screen, Vibrating Sifter Etc. Motion: Three Dimensional Movement
Diameter: 400mm~2000mm Material: Stainless Steel 304/316L, Carbon Steel Etc.
Optional: Discharge Gate, Quick Release Clamp, Magnetic Guard, Glass Viewing Port Etc. Customized: High Frequency Screen, Avalanche Screen, Low-profile Screen Etc.
Screen Frame: Glue Adhesive Type, Bolt Insert Type, Flange Type Etc. Mesh Cleaning Method: Bouncing Balls, Rotary Brush System, Ultrasonic Deblinding System Etc.
Application: Particle Size Grading, Impurity Removal, Filtering, De-watering, De-dusting, Lump Breaking, Cooling, Size Control Etc. Motor: One Unit Of Vibrating Motor, Verticle Arrangement
High Light:

1200mm SUS Vibrating Screening Machine

,

Oxide Pigment Vibrating Screening Machine

,

1200mm vibrating rock screen

Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment



Product Description of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment is a high-performance fine screening machine, which is mainly used for sieving, scalping, removing impurity, grading and filtering to improve product quality. Our team has rich experience for its usage in food, chemical, ceramic, medicine, metallurgy, pollution abatement.etc.

  This kind of vibration sieving machine is also known as the ound separator, circular vibratory screen, circular vibrating screen, circular vibrating sieve, rotary vibrating screen, rotary vibrating sieve, rvibro screen, vibrating sifter, round vibro sieve, gyro screen, gyro sieve, round sifter, round screener, round vibro sieve machine, round gyratory screen, rotary screen, rotatory vibrating screen, rotary vibrating sieve, gyro screen, gyro sifter, gyratory sifter, gyratory screen, gyratory sieving machine, vibro sifter, vibro separator, vibro grader, classic separator, vibratory separator, vibratory sifter, sanitary separators, filter sieve machine, industrial sifter etc.

  The rotary vibrating sifter machine is suitable for screening all of dry material (from 0.074mm to 20mm). And the diameter we can make are 400mm, 450mm, 500mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm. It supports at most 5 layers. But 1~3 layers are highly recommended. Because the more the layers, the worse the screening effect.



Application of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

1. Chemical Industry: pigment, colophony, dope, industry leechdom, cosmetic, paint etc.

2. Grinding Materials And china Industry: quartz, slurry, kaoline, carborundum, alumina, sprayer dust.
3. Metallurgy, Mining Industry: aluminum powder, welding rod powder, dioxide manganese, electrolyze copper powder, ceruse, copper powder, ore alloy powder, electromagnetic material, rubbing powder, fire-proof material, kaoline, lime, heavy calcium carbonate.

4. Food Industry: sugar, amylum, rice powder, milk powder, soyabean milk, angel cake, sauce, juice.
5. Paper-Making Industry: dope,white soil slurry, black and white liquid, disposed liquid, paper-making liquid and waste water recycling.



Working Principle of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 0

  The multi-layer rotary vibating sieve machine adopts the latest vertical vibrating motor, which produces a horizontal, vertical and oblique vibration of three dimensional, and then directly passes the vibration to screen surface. Changing the angle of the upper and lower eccentric block of the motor, it produces different exciting force, and the direction in which the material is running is changed.

  This round vibrating separator is made up of spring buffer, base, upper and lower heavy hammer,vibrating motor, screen frame, clamp ring, vibrating body, inlet and outlet port, dust proof cover and other parts. The exciting force will generate by the rotation of vibrating motor. The exciting force drives the vibrating body to vibrate. So the materials on the screen cloth can shake to reach the objective that filters different grade materials., The adjustable eccentric hammer is driven to the center line through the motor, caused centrifuged force under the state of unbalance and so that the materials from regular spiral. Speed and track of materials on the screen can be controlled by adjusting the angle of the two eccentric weights.



Optional APO Safety System (Automatic Power Off Safety System):

  The APO Safety System is integrated in the motor. In case of short circuit, phase loss, electric leakage and unstable voltage, the motor can cut off the power automatically to safeguard the machine and your staff.



Important Information You May Concern About Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 1

Model AY
Shape circular or round shape
Layers of Screen 1~5 layers of screen with 2~6 outlets
Mesh Size above 325 mesh
Screen Frame L type, ultrasonic type (transducer internal and external), adhesive type, etc.
Mesh Cleaning Method bouncing balls (rubber balls, silicone balls, polyurethane balls), ultrasonic system, rotary brush system etc.
Machine Diameter 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm etc.
Material stainless steel 304, 316L, carbon steel etc.
Function grading, solid-separation, remove the impurity etc.
Movement three dimensional vibration motion
Damping Spring carbon steel spring, stainless steel spring, air spring, rubber spring etc.
Motor one unit of verticle vibrating motor
Motor Brand China Made, OLI-WOLONG or other brand
Optional Design magnetic guard, quick release clamp, discharge gate, glass viewing port etc.



The general characteristics of the vibrator adjustment are described below:

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 2

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 3



Structure Diagram of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 4

Basic Function of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 5

1. Remove the impurity
The model can quickly separate a few oversize or undersized particles from a quantity of materials.



2. Solid-liquid separation
The mixture of solid and liquid can be separated effectively by single or multi-layer type into different grade materials.



3. Grading
Each model of vibrating sieve machine can precisely and continuously screen and separate screened products, the multi-layer type can screen and separate five groups of different particles at a time. It is suitable for dry materials.



Features of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

1. Fine screening.
On the rotary vibrating screen, the screen cloth is stainless steel wire woven mesh, the finest reach to 600 mesh (0.02mm). And the Counterweight Fast Adjustment System can control to regulate the material motion on screen cloth, and keep longer screening time to finish fine screening.



2. Rapid screen replacement:
The rotary vibrating screen adopts a very simple design to tension and install screen cloth, it is very easy to replace. Two staff could finish replacing in 10 minutes. The downtime could be reduced.



3. Good adaptability.
The rotary vibrating screen height could be customized specially based on customer requirement. Its outlet could be placed at 360 degree. It is very convenient to match other equipments in a production line. With IP65 protective grade motor, it could work against the ultrafine dust, liquid filtering and separating, high and low temperature, etc.



4. Fast adjustment counterweight system.
The vibrator motor is the key part of the machine. Its counterweights angle impact directly the material movement on screen cloth. To meet the needs of different screening, user have to adjust the counterweight angle and vibration force. The Fast Adjustment Counterweight System can help user to regulate the vibration force and material movement in a few minutes without dismantling machine. It is also very helpful to reduce downtime and improve the productivity.



5. Pollution-free production line.
Connected with soft hose to use, it can realize full-sealing working. No dust, no float powder, no liquid splashing, it is very suitable for sanitary production line, dust-free workshop, and also very helpful to safeguard your staff healthy.



6. Customize service
Various power voltages: 110V 220V 240V 380V 415V 450 V and 550V, different power frequencies, 50HZ or 60HZ, and even single phase electricity.
The mobile wheel, viewing hole, Valve, magnets, and frequency converter are available according to user's requirements.
The label service and OEM order are also available.



Optional Designs for Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:
1. Customised Dust Cover: it is used to reduce any leaks from the machine. It also helps reduce airborne dust from flowing on the steam or conveyer belt. This device is made custom to fit your production line.
2. Magnetic Guard: it is used for preventing any contamination and also to ensure that manufacturing is done safely and free from any irregularities. It captures particles with the use of high magnetic strength. The collected contaminants are then unleashed into the discharge chutes.

3. Discharge Gate: it is used to control production flow and speed. This enables a better flow and provides consistent discharge characteristics from even surfaces. However, the discharge rate might differ from the ratio and diameter of the discharge pipe.
4. Quick Release Clamp: it is used for releasing camps rings without the need to use tools. While the other side of the clamp is used for tightening. It is mostly used for cleaning and dissembling purposes.
5. Spring Dust Cover: it is used to provide additional protection against dust and other particles by the strength of the springs, which is determined by the rollers which are also spring-loaded.



Technical Parameters of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

Model Power Screen Surface Diameter Effective Screening Area (m2) Screen Decks
AY-400 0.18 KW 350mm 0.0962 1~3
AY-600 0.25 KW 550mm 0.2375 1~3
AY-800 0.55 KW 750mm 0.4416 1~3
AY-1000 0.75 KW 920mm 0.6644 1~3
AY-1200 1.1 KW 1120mm 0.9847 1~3
AY-1500 1.5 KW 1420mm 1.5829 1~3
AY-1800 2.2 KW 1720mm 2.3223 1~3
AY-2000 3.0 KW 1920mm 2.89 1~3

Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 6

Overall Dimensions of Diameter 1200mm Stainless Steel Rotary Vibrating Screen for Iron Oxide Pigment​:

Model A B C D E F G I Single Layer Height Double Layer Height

Three

Layer

Height

AY-400 472 372 150 400 110 60 300 270 550 660 770
AY-600 570 450 200 600 120 80 380 340 730 865 1000
AY-800 690 570 200 800 130 100 550 340 730 865 1000
AY-1000 810 690 250 970 150 120 650 400 790 925 1060
AY-1200 970 850 250 1170 180 130 760 450 860 1025 1190
AY-1500 1180 1060 250 1470 200 140 950 480 985 1180 1370
AY-1800 1480 1360 350 1770 220 150 1110 520 1030 1220 1410



Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 7Diameter 1200mm SUS Vibrating Screening Machine For Iron Oxide Pigment 8
