|Place of Origin:||China|
|Minimum Order Quantity:||1 Set|
|Packaging Details:||Fumigation-free plywood wooden case for export|
|Delivery Time:||20~30 work days after order confirmed|
|Payment Terms:||T/T, L/C|
|Supply Ability:||10 sets per month|
|Purpose:||Suitable For Eliminating Oversized Material Rapidly From Powders And Liquids||Diameter:||400mm~2100mm|
|Advantages:||Large Capacity, Compact Design, Fast Screen Replacement Etc.||Anti-Blinding Device:||Bouncing Balls, Ultrasonic System, Rotary Brush System Etc.|
|Driving Device:||Single Or Dual Vibrating Motors||Damping Spring:||Steel Spring, Rubber Spring Etc.|
|Material:||Carbon Steel, Stainless Steel 304, 316L Etc.||Application:||Cement, Flour, Starch, Milk Powder, Washing Powder, Metal Powder Or Granule, Additive, Chemicals Etc.|
inline vibrating screen sifter,
food grade vibrating screen sifter,
400mm vibrating screen sifter
Product Introduction of Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal:
Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal is also known as the flow-thru separator, flo-thru sifter, compact sieve, safety screeners, control sieves, low-profile vibrating sieve, low profile separator, inline vibrating screen etc. It is a powerful high-efficient machine that compacts high capacity scalping for both wet and dry materials.
This kind of sieve machine is suitable for dry, wet and various geometric materials. High performance, low noise, fully enclosed structure, no dust, good continuous separation of powder materials to meet a variety of needs.outlet materials can be discharge directly and meet the big capacity. The direct discharge vibrating screen is the two models of the same vibration motor mounted symmetrically on both sides of the screening machine, the vibration motor and lower ends are equipped with eccentric weights, generated during rotation of the horizontal, vertical , inclined three-dimensional movement, and by adjusting the material in the sieve the surface of the movement trajectory to reach the purpose of screening a variety of materials.
Some Important Information You May Concern About Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal:
|Alternative Name||flow-thru separator, compact sieve, check screening machine, safety screener, control sieve, inline vibrating sieve etc.|
|Motor||single vibrating motor, dual vibrating motors (optional)|
|Height||500mm or less (such as 300mm)|
|Mesh Debling System||ultrasonic deblinding system, bouncing balls, rotary brush etc.|
|Layers of Screen||1~2 layers of screens (multiple layers can be customized according to the specific situation)|
|Diameter||400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2100mm etc.|
|Discharge Port||the discharge port for fine particles are at the bottom of the machine|
|Purpose||suitable for materials safety screening with less oversize particles|
|Machine Shape||round, rectangular|
|Damping Spring||steel spring, rubber spring|
|Application||flour, starch, milk powder, additives, instant noodles, noodles, snacks, solid drinks etc.|
|Voltage||three-phase/380V, 415V, 440V etc.|
Working Principle of Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal:
The low profile flow-thru design employs two unbalanced-weight gyratory motors mounted on opposing exterior sidewalls of the unit, instead of one motor positioned beneath the screening chamber, reducing minimum height requirements significantly.
And this design also aligns the top inlet above the bottom outlet, allowing on-size material to descend through the screen in a straight-through path at high rates. Oversize material is ejected through a spout at the periphery of the screen.
Technical Parameters of Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal:
Note: the data above are for reference only, and our company reserves the right to modify the data.
Structure of Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal (A Sample):
Advantages of Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal:
1. Low profile.
2. Large handling capacity
3. Low power consumption
4. Automatic discharge the oversize materials
5. Easy to replace the screen, simple operation
Features of Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal:
1. Simple and compact structure , easy maintenance , Failure of small.
2. Fully enclosed structure , eliminate dust , noise , quiet and environmentally friendly.
3. The large flow spout at the bottom , to facilitate the installation of the pipeline operations.
4. Upper discharge port can be any adjustment within 360 ° for easy installation and use.
5. Processing capacity , high screening accuracy , and can effectively save energy , play a multiplier effect
6. The new network structure , network tension high , long service life , and customers can quickly replace the screen.
7. The energy consumption of our inline vibrating screen is small, while the noise could reach as low as 73-80 dB.
8. The protective grade of the motor comply with IP65, which means it is dustproof and waterproof. Besides, it is also heatproof and oil proof.
9. During the operation, if short circuit, phase loss or unstable voltage occurred, the motor will automatically cut off the power supply and stop working to make sure the motor will be not burnt out. Thus the electric element's damage can be reduced to an extremely low level.
Application of Food Grade Scraper Inline Vibrating Screen Sifter for Chicken Powder Meing Chellocken Meal:
1. Food industry:
Vibrating screen can be used for processing starch powder, sugar powder, sale, rice flour, milk power, soybean mile, sauce, fruit juice, condiment, and so on.
2. Chemical industry:
This vibrating sieve is widely used for handling resin powder, paint, industrial chemicals, detergent powder, cosmetic, Chinese medicine powder.
3. Metallurgy industry:
In metal processing industry, this inline vibrating screen can sift aluminum powder, lead powder, copper powder, alloy metal powder, electrode powder, manganese dioxide powder, electrolytic copper powder, abrasive powder, High temperature resistant material, kaolin, limestone, dolomite, alumina, calcium carbonate, quartz sand and so on.
4. Pollution abatement:
Our vibrating screen is also suitable for treating waste oil, sewage, accessory ingredient, activated carbon.
Contact Person: Ms. Magie
Alternative Name: flo-thru sifter, flow-thru separator, compact sieve, safety screeners, control sieves, low-profile vibrating sieve, low profile separator, inline vibrating screen etc.
Machine Diameter: 400mm~2100mm
Layers of Screen: 1~2 screen layers
Purpose: suitable for eliminating oversized materials rapidly from powders and liquids
Advantages: large capacity, short height, compact design, fast screen replacement etc.
Purpose: suitable for eliminating oversized material rapidly from powders and liquids
Machine Diameter: 600m~2100mm
Layers of Screen: 1~2 decks (multiple screen decks can be customized according to the specific situation)
