Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AY
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Moving Track: Three-dimensional Motion Work Level: Food Grade, General Grade, Pharmaceutical Grade Etc.
Mesh Cleaning System: Ultrasonic, Bounce Balls, Rotary Brush System Etc. Diameter: 400mm~2000 Mm (customizable)
Screen Material: Stainless Steel, Nylon, Polyurethane, Plastic Etc. Sieve Mesh: Perforated Plate, Woven Wire Mesh, Grizzly Bar Etc.
Vibrating Motor: Verticle Arrangement, Sufficient Power, Explosion Proof Optional Surface Finish: Mirror Finish, Paint, Sandblast, Etc.
High Light:

vibrating sieve screen

,

vibrating sieve separator

Introduction of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

High Efficiency Rotary Vibration Screening Machine for Diatom Ooze is is designed as a high-precision screening machinery, it is composed of a upper cover, a screen box, a base and a vertical motor with eccentric weight installed at two ends. It is also known as the vibro sifter, vibro shifer, vibro screen, gyro screen, round separator, circular vibrating screen, circular vibrating sieve, rotary vibrating screen, rotary vibrating sieve, etc.



Some Information You May Care About High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

Model AY
Shape round shape
Layers of Screen 1~5 layers of screen with 2~6 discharge ports (outlets)
Mesh Size above 325 mesh (according to the materials)
Screen Frame adhesive type, L type (bolt insert type), ultrasonic type (transducer internal and external), flange type etc.
Self-cleaning System bouncing balls (with ball decks, rubber balls, silicone balls etc.), ultrasonic de-blinding system, rotary brush system etc.
Diameter 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm etc.
Material stainless steel 304, 316L, carbon steel, plastic materials etc.
Surface Treatment Paint, sandblast and mirror polish etc.
Function solid-separation, grading, remove the impurity etc.
Movement three dimensional vibration motion
Damping Spring carbon steel spring, stainless steel spring, air spring, rubber spring etc.
Motor one set of vibrating motor, verticle arrangement (sufficient power), explosion proof optional
Motor Brand AAREAL Made, OLI-WOLONG, Italvibras etc.
APO Safety System Automatic Power Off Safety System is integrated in the motor
Quick-wear Parts

stainless steel woven wire mesh screen, perforated plate, bounce balls, clamps, springs, sealing rubber strip, verticle vibrating motor etc.

Optional Design collecting tray, discharge gate, magnetic guard, quick release clamp, glass viewing port, etc.
Work Level general grade, food grade, pharmaceutical grade etc.



Structure of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 0

  The circular round vibrating screen is made up of spring buffer, base, upper and lower heavy hammer,vibrating motor, screen frame, clamp ring,vibrating body, inlet and outlet port, dust proof cover and other parts. The exciting force will generate by the rotation of vibrating motor.



Purpose of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 1High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 2High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 3

                   Grading                        Solid-liquid Separation                    Impurity Removal



1. Classification: Granules/powder accurate classification
2. Filtration: Remove granules foreign matter in the liquid
3. Removal impurity: Remove the foreign matter or agglomerate



Working Principle of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 4

  The basic principle of rotary vibration filter sieve machine is the heavy hammer (unbalanced heavy hammer) installed in the electrical axis transform the motor's rotary motion into horizontal, vertical, and inclined three dimensional movement, then this movement passed to the screen surface. By adjusting the upper and lower ends of heavy hammer's phase angle, which can change the moving track of materials on the screen surface.



High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 5

High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 6



Characteristics of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

1. This rotary vibro sieve has a simple and functional design – This makes it run with sustained efficiency. It is also easier to use and has a higher capacity. Further, it is designed so that it can run with minimal supervision. It has a low-maintenance structure.

2. This sieve machine creates lower noise and covers a minimal floor space. Also, it is lightweight and can easily be transferred using a pallet jack or forklift. Now, it really comes in handy, right?

3. Consumes lower energy compared to conventional equipment – It does not sacrifice output quality. It not only generates premium outputs but also contributes to minimizing environmental damage.

4. It can work on its own for long hours – It does not entail much manual attention. In other words, its high durability makes it run with minimal supervision.

5. It has superb anti-binding properties – It helps to prevent screen clog neatly. Unlike other equipment, it does not create dust clouds as it operates. Like a robot, it has an automatic capacity to discharge separated materials.

6. It contains up to 5 layes of screen per unit – This makes it capable of conducting multiple operations with just a single unit; This is another feature which makes it cost effective. Moreover, its screen can easily be adjusted or changed in five minutes. Now, that’s quick enough.

7. The circular vibro sifter is made up of stainless steel, including all its contact parts – Even better, it can be fully or partially upgraded to SS316. This is to meet arising needs/demands. Likewise, it has various sizes and available modification schemes to suit all types of materials. Among these are different forms of powder and liquid.



Technical Parameters of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

Model Power Screen Surface Diameter Effective Screen Area (sqm) Decks
AY-400 0.18 KW 350mm 0.0962 1~3
AY-600 0.25 KW 550mm 0.2375 1~3
AY-800 0.55 KW 750mm 0.4416 1~3
AY-1000 0.75 KW 920mm 0.6644 1~3
AY-1200 1.1 KW 1120mm 0.9847 1~3
AY-1500 1.5 KW 1420mm 1.5829 1~3
AY-1800 2.2 KW 1720mm 2.3223 1~3
AY-2000 3.0 KW 1920mm 2.89 1~3

 Note: our company reserve the right to modify the above data.



Overall Dimensions of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 7

Model A B C D E F G I

Single Layer

Height

Double

Layer

Height

Three

Layer

Height

AY-400 472 372 150 400 110 60 300 270 550 660 770
AY-600 570 450 200 600 120 80 380 340 730 865 1000
AY-800 690 570 200 800 130 100 550 340 730 865 1000
AY-1000 810 690 250 970 150 120 650 400 790 925 1060
AY-1200 970 850 250 1170 180 130 760 450 860 1025 1190
AY-1500 1180 1060 250 1470 200 140 950 480 985 1180 1370
AY-1800 1480 1360 350 1770 220 150 1110 520 1030 1220 1410



Application of High Efficiency Rotary Vibration Screening Machine for Diatom Ooze:

1. Chemical industry: PVC powder, resin, pigment, rubber, industrial medicine, cosmetic, coatings, etc.

2. Food industry: Sugar powder, starch, egg powder, sauce, salt, rice noodles, milk powder, soybean milk, syrup, etc.

3. Social pollution disposed: Disposed oil, disposed water, disposed dye water, assistant, active carbon.
4. Ceramic and abrasive: Alumina, quartz sand, mud etc.

5. Metal, metallurgy and mining industry: Aluminum powder, ceruse, copper powder, ore alloy powder, welding rod powder, electrolysis copper powder, electromagnetism materials, manganese dioxide, grinding powder, fire-resistant material, lime, heavy calcium carbonate, alumina, etc.
6. Pharmacy profession: western medicine powder, liquid, Chinese herbal medicine, particle, etc.
7. Paper making: Paper pulp, paint, wasted water recycling.



High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 8High Efficiency Rotary Vibration Screening Machine for Diatom Ooze 9
