Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener

  • Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener
  • Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener
Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AY
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Other Names: Vibro Sieve, Vibro Screen, Vibrating Sifter, Round Separator Etc. Optional: Quick Release Clamp, Discharge Gate, Magnetic Guard, Glass Viewing Port Etc.
Customized: Low-profile Screen, High Frequency Screen, Avalanche Screen Etc. Motion: Three Dimensional Movement
Screen Frame: Bolt Insert Type, Glue Adhesive Type, Flange Type Etc. Motor: One Unit Of Vibrating Motor, Verticle Arrangement
Mesh Cleaning Method: Bouncing Balls, Ultrasonic Deblinding System, Rotary Brush System Etc. Application: Particle Size Grading, Impurity Removal, Filtering, De-watering, De-dusting, Lump Breaking, Cooling, Size Control Etc.
High Light:

round vibrating screen

,

round separator

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener



Product Description of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​:

Aluminium Oxide Rotary Vibro Screening Machine with High Precision is a high performance fine screening machine, used mainly for sieving, scalping, removing impurity, grading and filtering to improve product quality. Our team has rich experience for its usage in food, chemical, ceramic, medicine, metallurgy, pollution abatement.etc.

  The rotary vibrating sifter machine is suitable for screening all of dry material (from 0.074mm to 20mm). This screening machine dimension is ranged from diameter 450mm, 500mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm. It supports at most 5 layers. But 3 layers are highly recommended.

  This kind of sieving machine is also known as the circular vibratory screen, circular vibrating screen, circular vibrating sieve, rotary vibrating screen, rotary vibrating sieve, round separator, vibro screen, vibrating sifter, round vibro sieve, gyro screen, gyro sieve, round sifter, round screener, round vibro sieve machine, round gyratory screen, rotary screen, rotatory vibrating screen, rotary vibrating sieve, gyro screen, gyro sifter, gyratory sifter, gyratory screen, gyratory sieving machine, vibro sifter, vibro separator, vibro grader, classic separator, vibratory separator, vibratory sifter, sanitary separators, filter sieve machine, industrial sifter etc.



Working Principle of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​​​:

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 0

  The multi-deck rotary vibating screen separator adopts the latest vertical vibrating motor, which produces a horizontal, vertical and oblique vibration of three dimensional, and then directly passes the vibration to screen surface. Changing the angle of the upper and lower eccentric block of the motor, it produces different exciting force, and the direction in which the material is running is changed.

The rotary vibrating screen filter sieve machine is made up of spring buffer, base, upper and lower heavy hammer,vibrating motor, screen frame, clamp ring, vibrating body, inlet and outlet port, dust proof cover and other parts. The exciting force will generate by the rotation of vibrating motor. The exciting force drives the vibrating body to vibrate. So the materials on the screen cloth can shake to reach the objective that filters different grade materials., The adjustable eccentric hammer is driven to the center line through the motor, caused centrifuged force under the state of unbalance and so that the materials from regular spiral. Speed and track of materials on the screen can be controlled by adjusting the angle of the two eccentric weights.



Optional APO Safety System (Automatic Power Off Safety System):

  The APO Safety System is integrated in the motor. In case of short circuit, phase loss, electric leakage and unstable voltage, the motor can cut off the power automatically to safeguard the machine and your staff.



Important Information You May Concern About Aluminium Oxide Rotary Vibro Screening Machine with High Precision:

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 1

Model AY
Shape circular or round shape
Layers of Screen 1~5 layers of screen with 2~6 outlets
Mesh Size above 325 mesh
Screen Frame adhesive type, L type, ultrasonic type (transducer internal and external) etc.
Mesh Cleaning Method bouncing balls, ultrasonic system, rotary brush system etc.
Machine Diameter 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm etc.
Material stainless steel 304, 316L, carbon steel etc.
Function grading, solid-separation, remove the impurity etc.
Movement three dimensional vibration motion
Damping Spring carbon steel spring, stainless steel spring, air spring, rubber spring etc.
Motor verticle vibrating motor
Motor Brand China Made, OLI-WOLONG or other brand
Optional Design magnetic guard, quick release clamp, discharge gate, glass viewing port etc.



The general characteristics of the vibrator adjustment are described below:

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 2

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 3



Structure Diagram of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​:

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 4

Basic Function of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​:

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 5

1. Remove the impurity
The model can quickly separate a few oversize or undersized particles from a quantity of materials.



2. Solid-liquid separation
The mixture of solid and liquid can be separated effectively by single or multi-layer type into different grade materials.



3. Grading
Each model of vibrating sieve machine can precisely and continuously screen and separate screened products, the multi-layer type can screen and separate five groups of different particles at a time. It is suitable for dry materials.



Features of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​:

1. Rapid screen replacement:
The rotary vibrating screen adopts a very simple design to tension and install screen cloth, it is very easy to replace. Two staff could finish replacing in 10 minutes. The downtime could be reduced.



2. Fine screening.
On the rotary vibrating screen, the screen cloth is stainless steel wire woven mesh, the finest reach to 600 mesh (0.02mm). And the Counterweight Fast Adjustment System can control to regulate the material motion on screen cloth, and keep longer screening time to finish fine screening.



3. Good adaptability.
The rotary vibrating screen height could be customized specially based on customer requirement. Its outlet could be placed at 360 degree. It is very convenient to match other equipments in a production line. With IP65 protective grade motor, it could work against the ultrafine dust, liquid filtering and separating, high and low temperature, etc.



4. Fast adjustment counterweight system.
The vibrator motor is the key part of the machine. Its counterweights angle impact directly the material movement on screen cloth. To meet the needs of different screening, user have to adjust the counterweight angle and vibration force. The Fast Adjustment Counterweight System can help user to regulate the vibration force and material movement in a few minutes without dismantling machine. It is also very helpful to reduce downtime and improve the productivity.



5. Pollution-free production line.
Connected with soft hose to use, it can realize full-sealing working. No dust, no float powder, no liquid splashing, it is very suitable for sanitary production line, dust-free workshop, and also very helpful to safeguard your staff healthy.



6. Customize service
Various power voltages: 110V 220V 240V 380V 415V 450 V and 550V, different power frequencies, 50HZ or 60HZ, and even single phase electricity.
The mobile wheel, viewing hole, Valve, magnets, and frequency converter are available according to user's requirements.
The label service and OEM order are also available.



Application of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​:

1. Chemical Industry: colophony, dope, industry leechdom, cosmetic, paint

2. Food Industry: sugar, amylum, rice powder, milk powder, soyabean milk, angel cake, sauce, juice.
3. Paper-Making Industry: dope,white soil slurry, black and white liquid, disposed liquid, paper-making liquid and waste water recycling.
4. Grinding Materials And china Industry: quartz, slurry, kaoline, carborundum, alumina, sprayer dust.
5. Metallurgy, Mining Industry: aluminum powder, welding rod powder, dioxide manganese, electrolyze copper powder, ceruse, copper powder, ore alloy powder, electromagnetic material, rubbing powder, fire-proof material, kaoline, lime, heavy calcium carbonate.



Technical Parameters of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​:

Model Power Screen Surface Diameter Effective Screening Area (m2) Screen Decks
AY-400 0.18 KW 350mm 0.0962 1~3
AY-600 0.25 KW 550mm 0.2375 1~3
AY-800 0.55 KW 750mm 0.4416 1~3
AY-1000 0.75 KW 920mm 0.6644 1~3
AY-1200 1.1 KW 1120mm 0.9847 1~3
AY-1500 1.5 KW 1420mm 1.5829 1~3
AY-1800 2.2 KW 1720mm 2.3223 1~3
AY-2000 3.0 KW 1920mm 2.89 1~3

Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 6

Overall Dimensions of Aluminium Oxide Rotary Vibro Screening Machine with High Precision​​​:

Model A B C D E F G I Single Layer Height Double Layer Height

Three

Layer

Height

AY-400 472 372 150 400 110 60 300 270 550 660 770
AY-600 570 450 200 600 120 80 380 340 730 865 1000
AY-800 690 570 200 800 130 100 550 340 730 865 1000
AY-1000 810 690 250 970 150 120 650 400 790 925 1060
AY-1200 970 850 250 1170 180 130 760 450 860 1025 1190
AY-1500 1180 1060 250 1470 200 140 950 480 985 1180 1370
AY-1800 1480 1360 350 1770 220 150 1110 520 1030 1220 1410



Optional Designs for Aluminium Oxide Rotary Vibro Screening Machine with High Precision​:
1. Customised Dust Cover: it is used to reduce any leaks from the machine. It also helps reduce airborne dust from flowing on the steam or conveyer belt. This device is made custom to fit your production line.
2. Magnetic Guard: it is used for preventing any contamination and also to ensure that manufacturing is done safely and free from any irregularities. It captures particles with the use of high magnetic strength. The collected contaminants are then unleashed into the discharge chutes.

3. Discharge Gate: it is used to control production flow and speed. This enables a better flow and provides consistent discharge characteristics from even surfaces. However, the discharge rate might differ from the ratio and diameter of the discharge pipe.
4. Quick Release Clamp: it is used for releasing camps rings without the need to use tools. While the other side of the clamp is used for tightening. It is mostly used for cleaning and dissembling purposes.
5. Spring Dust Cover: it is used to provide additional protection against dust and other particles by the strength of the springs, which is determined by the rollers which are also spring-loaded.



Aluminium Oxide Rotary Vibrating Screen , High Precision Tumbler Screener 7
