Introduction of 300*1000mm Food Grade Stainless Steel Rotary Centrifugal Sifter Turbo Sifter for Spices Screening:
The 300*1000mm Food Grade Stainless Steel Rotary Centrifugal Sifter Turbo Sifter for Spices Screening is highly effective at sifting, scalping and de-agglomerating of fines or micro powder. We offer a broad range of models and configurations to screen your particular material with superior efficiency. It is a non-vibratory screening machine.
This airflow screen can be also called rotary sifter, centrifugal sifter, turbo sieve, rotary screen, airflow screen, airflow centrifugal sifter, centrifugal screener, centrifugal powder sifter, centrifugal sieve, airflow sieve, horizontal airflow screen, cyclone sieve, air classifier etc.
Working Principle of 300*1000mm Food Grade Stainless Steel Rotary Centrifugal Sifter Turbo Sifter for Spices Screening:
The cylinder screen mesh of this centrifugal sifter screens is placed inside the machine. The materials enter the net tube with airflow mixed and atomized after passing the screw conveying system; some of the materials are sprayed through the net and discharged from the fine stuff portal by the centrifugal force and cyclone propelling power, which are caused by the rotor vane inside the net tube. Other materials which cannot cross the net, are discharged from the rough stuff portal along the net tube wall.
Features of 300*1000mm Food Grade Stainless Steel Rotary Centrifugal Sifter Turbo Sifter for Spices Screening:
1. Small size, light weight, steady and no vibration, no noise, good sealing performance, no dust and high efficiency.
2. The shell structure is novel. Easy to control. Simple installation and low requirement for laying foundation.
3. It can be used by single machine or matching with multi-machines. Long time continuous operation. Safe and reliable.
4. The screen mesh is washed by the cyclone and can be automatically cleared. It can be equipped with a variety of material screens: stainless steel wire mesh, stainless steel or carbon steel punching hole mesh. Long service life. The nylon fiber screen has anti-static and automatic cleaning function.
5. Screening and crushing into one. It has the recrushing function to the caking material.
6. Without static electricity in the operation. The friction in the screening process is small. Not easy to produce static electricity.
7. This machine can be matched with the pneumatic conveying system, directly connected into the wind path, saving resources.
8. New design: The gas protection system can deliver the purified air to both ends of the equipment, which can effectively reduce the temperature produced by the equipment during operation. The gas isolation layer is formed on the bearing, thereby preventing dust from entering, effectively prolonging the service life of the bearing, reducing the maintenance frequency and improving the work efficiency.
Important Information You May Care About 300*1000mm Food Grade Stainless Steel Rotary Centrifugal Sifter Turbo Sifter for Spices Screening:
Name
centrifugal sifter, rotary sifter, airflow screen, turbo sieve etc.
Model
AL-18-65, AL-30-100, AL-50-130 (special model can be customized)
stainless steel woven wire mesh, nylon mesh, wedge screen etc.
Layers of Screen
single layer of screen
Mesh Size
below 500 mesh
Purpose
for sieving materials of sticky, static and multi-fiber etc.
Application
calcium carbonate, diatomite, silica sand, quartz powder, diatomite, white cement, battery material, starch, chili powder, glucose powder, herbal powder etc.
General Type Cantilever Type
Stainless Steel Woven Wire Mesh Nylon Mesh
Overall Dimensions of Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
Model
A
B
C
D
E
F
G
H
I
J
AL-18-65
1430
460
420
1005
135
230
250
330
340
210
AL-30-100
1845
655
766
1240
320
285
300
350
380
290
AL-50-130
2230
870
790
1775
280
515
150
660
400
485
Note: we can design and manufacture special type of sieving machine according to user's requirement.
Technical Parameters of 300*1000mm Food Grade Stainless Steel Rotary Centrifugal Sifter Turbo Sifter for Spices Screening:
Model
Material
Apply to
AL-18-65
Q235A, SUS304
< 500 mesh
AL-30-100
Q235A, SUS304
< 500 mesh
AL-50-130
Q235A, SUS304
< 500 mesh
Application of 300*1000mm Food Grade Stainless Steel Rotary Centrifugal Sifter Turbo Sifter for Spices Screening:
The centrifugal sifter is used for sieving materials of sticky, static and multi-fiber. Applicable to metallurgy, mining, pharmaceutical, food, chemical, metal powder and non-metal industries etc.
Such as Chinese medicine powder, battery material, starch, glucose powder, xylitol, soybean protein, peanut protein, vitamin C, sorbitol, ganoderma lucidum powder, malt powder, coffee powder, bread powder, flour, condiments, food additives, traditional Chinese medicine powder, APIs, pharmaceutical raw materials, active pharmaceutical ingredients, pharmaceutical intermediates, glass beads, perlite, silicon carbide, silicon powder, activated carbon, epoxy resin, polyethylene powder, fire extinguishing agent, zircon powder, pigment (phthalocyanin blue, phthalocyanin red, phthalocyanin yellow, yellow lead, high sand ceramic pigments etc.), magnetic material, drill powder, pyrophyllite powder, barium sulfate, lithium manganese oxide, zinc borate, coal ash, silicon powder, glaze, powder coating, pollen, dehydrated vegetable, egg powder, milk powder, soda powder, essence, magnesium oxide, magnesium hydroxide, calcium oxide, silicon nitride, alumina, molybdenum disulfide, cellulose, nanograde titanium dioxide, PVC resin powder, barium sulfate, silica gel powder, guar bean gum, calcium fluoride and other powder materials.
