Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening

Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening

  • Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening
  • Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening
  • Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening
Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AGTS
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: E-mail: sale@aarealmachine.com
Delivery Time: https://www.aarealmachine.com
Supply Ability: WhatsApp: 0086-15637361027
Contact Now
Detailed Product Description
Alternative Names: Rotary Screen, Rotary Sifter, Trommel Screen, Drum Screen, Revolving Screen, Cylinder Round Sifter Etc. Moving Trajectory: Rotary Centrifugal Motion
Angle Of Inclination: 5°~7° Type: Shaft Design, Shaft-less Design
Shape: Cylindrical, Hexagonal Etc. Segment: 1~4 Segment (layers Of Screen)
Screen: Woven Wire Mesh, Wedge Screen, Perforated Sieve Plate Etc. Mesh De-blinding: Self-cleaning
Material: Carbon Steel, Stainless Steel 304, 316L Etc. Application: Titanium Dioxide, Sand And Gravel, Sugar, Wood Chips, Spices Etc.

Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening



Introduction of Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening:

  There are two kinds of rotary trommel screens: shaft type and shaft-less type.

  The trommel screen overcomes the problem of screen sticking and blocking that occurs when ordinary vibrating screen sift wet materials, improves the output and reliability of the screening system, and is suitable for screening materials of various properties, as well as coal, coal gangue, and coke production. Moist and easy to block materials such as slaked lime, the product under the sieve is as thick as 100mm, the middle is 10-50mm, and the thickness can be less than 3mm. It is a good choice for the classification of refractory materials, coal, sand, sandstone block, limestone, metallic or non-metallic minerals etc.



Some Important Information About Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening:

Other Names rotary screen, rotary sifter, trommel screen, drum screen, revolving screen, cylinder round sifter etc.
Movement rotary centrifugal movement
Power Source general motor and reducer
Type closed type, open type; with shaft, shaftless design
Shape hexagonal, cylindrical
Angle of Inclination 5°~7°
Material carbon steel, stainless steel 304, 316L etc.
Advantages overcome the screen mesh plugging problem caused by circular vibrating screen and linear screen in the process of screening wet materials
Features has strong adaptability to materials. Material that is sticky, with high humidity, dirty and miscellaneous can be screened
Application sugar, sand, gold, quicklime, refractory materials, coal, wood chips etc.



Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening 0

                         Shaft Type Trommel Screen                                        Shaft-less Trommel Screen



Shaft Trommel Screen: it can sift granular, powdered and lumpy materials.

Shaft-less Trommel Screen: Shaft-free design can be used for screening of materials with easy winding, large volume and large impact capacity.



Technical Parameters of Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening:

Model

Capacity

(t/h)

Screen Drum Diameter (mm)

Length

(m)

Motor Power (KW)
AGTS-600 5-10 600 1000 1.5
AGTS-800 8-15 800 1200 2.2
AGTS-1000 15-30 1000 1500 3
AGTS-1200 20-50 1200 1800 5.5
AGTS-1500 40-80 1500 2000 7.5
AGTS-1800 80-150 1800 2000 11
AGTS-2000 130-200 2000 2500 11



Working Principle of Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening:

  The main structure of rotary trommel screen is sieving cylinder, which is composed of several circular shape of the screen. The whole and ground plane is in heeling condition. External sealed the isolation cover seal is to prevent the pollution of the environment. The speed reducing system enables the screening cylinder rotates at a certain speed. Thus the material is separated by sieving cylinder from top to bottom. Afterwards fine material is discharged from the lower front part of sieving cylinder. While coarse material discharged from the tail end of the screening cylinder.

Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening 1

                              Material Running State in the Rotary Screen



Structure of Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening:

Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening 2



1. driving device    2. coarse material discharge opening    3. seal cover

4. drum body    5. undersize material discharge opening    6. retaining plate

7. feed inlet    8. bracket



Advantages of Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening:
1. High screening efficiency equipment can be equipped with comb type cleaning mechanism.

2. Wide adaptability of materials.
3. Its own energy consumption is small, long service life, small maintenance.

4. The screen feeding method is simple and diverse.

5. The screen component is large, easy to enlarge.
6. Equipment noise is low, working environment is good.



Application of Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening:

1. Food industry: sugar powder, monosodium, starch, salt, milk powder, egg powder, rice powder, bread crumbs, soy milk, sauce, juice, food additive, etc.

2. Metal, metallurgy industry: titanium dioxide, aluminum powder, ceruse, copper powder, nickel powder, ore alloy powder, welding powder, battery material, abrasive powder, fire proof material, alumina .

3. Chemical industry: fertilizer, detergent powder , talcum powder, talcum powder, dyestuff, rubber, resin, pigment, industrial medicine, cosmetic, coatings, Chinese medicine powder .

4. Other industry: paper-making industry, ceramic industry, mining industry, pharmaceuticals industry etc.



Stainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet ScreeningStainless Steel Shaftless Rotary Trommel Screen for Titanium Dioxide Wet Screening
