Dia. 400mm Stainless Steel Tubular Industrial Conveyor Systems Food Industry

Dia. 400mm Stainless Steel Tubular Industrial Conveyor Systems Food Industry

  • Dia. 400mm Stainless Steel Tubular Industrial Conveyor Systems Food Industry
  • Dia. 400mm Stainless Steel Tubular Industrial Conveyor Systems Food Industry
  • Dia. 400mm Stainless Steel Tubular Industrial Conveyor Systems Food Industry
Dia. 400mm Stainless Steel Tubular Industrial Conveyor Systems Food Industry
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AS
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: L/C, T/T
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Type: Tubular Vibration Type Characteristics: Good Heat Insulation Effect, Large Conveying Capacity, Low Power Consumption, Simple Structure, Easy Debugging, Easy Installation
Installation: Seat-type Installation Or Short-distance Hanging Installation Motor Installation: Motor Up-vibration Type, Motor Down-vibration Type
Applicable Material: Suitable For Conveying All Kinds Of Powder, Granular, Lump And Mixtures With Temperature Below 300℃ Application: Used In Metallurgy, Chemical, Building Materials, Coal And Other Industries
High Light:

Tubular Industrial Conveyor Systems

,

400mm Industrial Conveyor Systems

,

400mm tubular vibrating conveyor

Dia. 400mm Stainless Steel Tubular Vibrating Feeding Conveyor for Food Industry



Overview of Dia. 400mm Stainless Steel Tubular Vibrating Feeding Conveyor for Food Industry:

  Tubular Vibrating feeders are suitable for handling and dosing of free flowing bulk material with a max. grain size of 1/3 of the tube diameter. Especially when the conveying process has to be dust free, tubular vibrating feeders are an ideal solution due to their closed design, which also provides high standards of hygiene and cleanliness. For feeding poisonous and hazardous substances, vibrating tube conveyors / feeders are the industries preferred solution.



Application Range of Dia. 400mm Stainless Steel Tubular Vibrating Feeding Conveyor for Food Industry:

  The vibrating conveyor can be widely used in powder and granular materials transportation in metallurgy, coal, building materials, chemical, glass, electric power, machinery, food and other industries. The delivery volume and structure can also be designed according to user requirements.



Features of Dia. 400mm Stainless Steel Tubular Vibrating Feeding Conveyor for Food Industry:

1. Dust free operation

2. Accurate, repeatable performance
3. Maintains material integrity
4. Low maintenance – no internal moving parts, easy to clean
5. Explosion-proof certification available



Main Technical Parameters of Dia. 400mm Stainless Steel Tubular Vibrating Feeding Conveyor for Food Industry:

Model Capacity (t/h) Conveying Distance (mm) Power (kw) Weight (kg)
AS-30-250 30 2500 2*0.4 410
AS-30-300 25 3000 2*0.4 490
AS-50-350 50 3500 2*0.75 650
AS-50-400 40 4000 2*0.75 740
AS-50-450 30 4500 2*0.75 840
AS-50-500 80 5000 2*1.5 1050
AS-50-550 70 5500 2*1.5 1150
AS-50-600 60 6000 2*1.5 1250
AS-50-650 50 6500 2*1.5 1350
AS-50-700 40 7000 2*1.5 1450
AS-50-750 30 7500 2*1.5 1550
AS-70-800 145 8000 2*2.2 2400
AS-70-850 135 8500 2*2.2 2550
AS-70-900 125 9000 2*2.2 2700
AS-70-900 110 9500 2*2.2 2850
AS-70-1000 100 10000 2*2.2 3000



Dia. 400mm Stainless Steel Tubular Vibrating Feeding Conveyor for Food IndustryDia. 400mm Stainless Steel Tubular Vibrating Feeding Conveyor for Food Industry

       Tubular Trough Vibrating Conveyor                    U-type Trough Vibrating Conveyor
