Ss304 450mm Vibrating Filter Sieve For Powder Coating
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AY-450
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 7~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 50 sets per month
Contact Now
Detailed Product Description
Diameter: About 450mm Type: Seat Type, Portable Type (optional)
Purpose: Suitable For Powder Screening And Slurry Filtration With Less Impurity Content Material Discharge: The Undersize Material Will Be Discharged Automatically From The Outlet, And The Oversize Should Be Dumped Manually
Material: Stainless Steel 304 Movement: Noiseless Three Dimensional Vibration
Advantage: Small Size, Easy To Clean And Dump The Impurities Application: Paint Coating, Glaze Powder, Soybean Milk, Oil Paint Etc.
High Light:

powder coating vibrating filter sieve

,

450mm vibrating filter sieve

,

ss304 vibrating filter sieve

Product Overview of Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating:

Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating, is also known as the 450 type filter sieve separator, is a kind of small vibrating filter sieve which is easy to move, with high efficiency, low noise and small volume. It is especially suitable for powder screening and slurry filtration with less impurity content, such as soya-bean milk, powder coating, glaze, ceramic mud, paint etc. The 325 mesh screen filter paint with a specific gravity of 1.1 can reach 1200 liters per hour, and the 30 mesh screen can handle 700 kilograms per hour flour. It has an excellent filtration performance for ceramic uranium material.



Working Principle of Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating:
  The 450 type vibrating filter sieve adopts a new type of vertical vibration motor as the vibration source. The upper and lower ends of the vertical vibration motor are equipped with eccentric weights, which can generate horizontal, vertical and inclined three-dimensional motion. The exciting force is transmitted to the screen frame and materials through the receiving pan to achieve an excellent grade. By adjusting the phase angle of the upper and lower eccentric weight hammer, the movement track of the material on the screen surface can be changed to ensure the full grading of the material.



Product Advantages of Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating:

1. Small volume, low noise, easy to move, the discharge port can be arranged along the circumferential direction.
2. High sseving accuracy and high efficiency, can be used in any powder, granule or mucus.
3. Fully enclosed structure, the powder is not flying, the mesh is not blocked, and sieving powder can reach 400 mesh.

4. It is easy to replace the screen, easy to operate and easy to clean.
5. The machine is equipped with mesh anti-blocking device, which can effectively eliminate the blockage of the mesh.

6. The mixed materials enter from the center. After sieving, the materials of various particle sizes are automatically and continuously discharged from the respective outlets, which can realize continuous production.
7. There are no special requirements for the equipment foundation, and the general cement floor can be used directly.

Structural Features of
Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating:
1. The upper screen frame can be easily removed, and it is very convenient to pour off impurities that do not pass through the screen.
2. The material is directly discharged. There is no dead angle in the screen machine, and no secondary pollution is generated.
3. A nylon brake wheel can be added for easy movement.
4. A waterproof cover is added to prevent electricity from water.

5. It is convenient to remove and change the screen by using the internal V-type screen pressing way.

Technical Parameters of Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating:

Name Diameter Power Noise Dimensions Voltage Amplitude
Data 450mm 0.18 KW ≤50dB 460*550*665mm 380V, 220V 2~5mm



Structural Composition of Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating:
  The 450 type filter machine consists of the body, vibrating motor, hopper, screen frame, electronic control unit etc. The machine adopts a new type of vibration structure with stable vibration and high efficiency. The screen frame is easy to operate, easy to clean, and easy to replace the screen. This machine has the advantages of novel appearance, reasonable structure and easy to operate, and is more suitable for occasions where the working place is frequently changed.
Ss304 450mm Vibrating Filter Sieve For Powder Coating 0

Screen Replacement of
Stainless Steel 304 Food Grade 450 Type Noiseless Vibrating Filter Sieve for Powder Coating:
  First remove the screen frame from the receiving pan, loosen the bolts, remove the screen that needs to be replaced, and then spread the new screen on the screen frame, and put the screen holder, and draw it around (avoid being too tight), leave a centimeter along the mesh ring, put on the bolts and tighten, and finally cut off the excess screen.



Ss304 450mm Vibrating Filter Sieve For Powder Coating 1Ss304 450mm Vibrating Filter Sieve For Powder Coating 2
