High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes

High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes

  • High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes
  • High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes
High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Feature: High-frequency Vibration Exciting Force: 3KN~15KN
Purpose: Used In Dry-wet Filter, Grading And Dewatering Of Various Materials Movement: Three Dimensional Vibration
Power Source: One Set Of Verticle Vibrating Motor Material: Stainless Steel 304, 316L Etc.
Characteristics: Low Energy, Small Size, Light, Easy To Move And Height Freely Adjusted Application: Ceramics, Chemical Industry, Brick Making, Food, Pharmacy, Chemical Fertilizer And Papermaking
High Light:

wet vibrating screen

,

sieve separator machine



High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes



Introduction of Stainless Steel High Frequency Vibrating Filter Sieve for Ceramic Glazes​:

Stainless Steel High Frequency Vibrating Filter Sieve for Ceramic Glazes is widely used in dry-wet filter, grading and dewatering of various materials in ceramics, chemical industry, brick making, food, pharmacy, chemical fertilizer and papermaking. For fine-grading operations in the grinding process of the concentrator, under the condition of the appropriate feed concentration, feed size (1-200 mesh size), and the difference between particle size and feed size less than 30% of the high-frequency screen, the screening efficiency is more than 70%.

  Due to the high-efficiency, it can greatly reduce the circulating load and the qualified grain size content on the sieve, thereby improving the processing capacity of the sifter (generally being improved 5-10%). The sieving process controls the particle size strictly under the sieve, and eliminates the adverse effect of the coarse ore on the fine ore; slurry, under high-frequency vibration of small amplitude of the screen surface, has the function of stratification according to density, high-density small particles easy to sink to the screen surface and through the screen, which can significantly improve the quality of the material under the screen.



Features of Stainless Steel High Frequency Vibrating Filter Sieve for Ceramic Glazes:

1. High efficient with low energy, automatic grading, smooth movement, low noise, continuous production.
2. New grid structure, the long service life of screen, no deformation of the mesh, changing the screen mesh only take 3-5 minutes, no angle without reaching, easy to clean and disinfect.
3. High-power and high-frequency motor, with a water-proof and dust-proof device, long service life, more safe and secure.
4. Fully sealed, the liquid not exposed, large capacity, high screening accuracy, the smallest particle size can be screened to 500 mesh.
5. All kinds of slurry in the insoluble material can be quickly removed, the residue automatically discharged.
6. Small size, light weight, simple operation, easy maintenance.



Moving Trajectory of Stainless Steel High Frequency Vibrating Filter Sieve for Ceramic Glazes:

High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes 0



Technical Parameters of Stainless Steel High Frequency Vibrating Filter Sieve for Ceramic Glazes:

Diameter

(mm)

Power

(kw)

Effective Diameter of Mesh

(mm)

Exciting Force(kN)

Weight

(kg)

450 0.18 420 3 50
600 0.25 600 5 65
800 0.55 800 8 78
1000 0.75 970 10 130
1200 1.1 1170 15 170



Application of Stainless Steel High Frequency Vibrating Filter Sieve for Ceramic Glazes:

  The high frequency vibrating filter screen machine is suitable for food, pharmacy, chemical, products, ceramic, powder, metallurgy, plastics, rubber, grinding and other industries.

1. Food industry: starch juice, soybean milk, beverages, dairy products, spices
2. Chemical industry: paint, printing ink, color paste, beverages, paint latex paint, aluminum paste
3. Other industries: mud slurry, ceramic mud, liquid waste, Chinese and Western liquid medicine

High Frequency Rotary Sifter Machine Stainless Steel For Ceramic Glazes 1
