| Place of Origin: | China |
| Brand Name: | AAREAL |
| Certification: | ISO9001:2015 |
| Model Number: | AL |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Fumigation-free plywood wooden case for export |
| Delivery Time: | 15~35 work days after order confirmed |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10 sets per month |
| Other Names: | Rotary Sifter, Turbo Sieve, Centrifugal Sifter, Airflow Screen Etc. | Purpose: | Used For Sieving Materials Of Sticky, Static And Multi-fiber Etc. |
|---|---|---|---|
| Surface Treatment: | Paint, Sandblast, Mirror Finish Etc. | Machine Material: | Carbon Steel, Stainless Steel 304, 316L Etc. |
| Screen Material: | Nylon Mesh, Stainless Steel Woven Wire Mesh, Wedge Mesh Etc. | Layers Of Screen: | Only One Layer Of Screen Mesh |
| Screen Cage Size: | Diameter*length 180*650mm, 300*1000mm, 500*1300mm Etc. | Mesh Cleaning Method: | De-blinding With Air, Rubber, Brush Etc. |
| Mesh Size: | Below 500 Mesh, Or ≥0.028mm | Application: | Cosmetics, Starch, Calcium Carbonate, Diatomite, White Cement, Battery Material Etc. |
| High Light: | rotary sifter machine,rotary trommel screen |
||
Wheat Gluten Airflow Centrifugal Machine Rotary Sieve Separator Machine
Introduction of Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
The Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten is highly effective at sifting, scalping and de-agglomerating of fines or micro powder. We offer a broad range of models and configurations to screen your particular material with superior efficiency. It is a non-vibratory screening machine.
This airflow screen can be also called rotary sifter, centrifugal sifter, turbo sieve, rotary screen, airflow screen, airflow centrifugal sifter, centrifugal screener, centrifugal powder sifter, centrifugal sieve, airflow sieve, horizontal airflow screen, cyclone sieve, air classifier etc.
Working Principle of Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
The cylinder screen mesh of this centrifugal sifter screens is placed inside the machine. The materials enter the net tube with airflow mixed and atomized after passing the screw conveying system; some of the materials are sprayed through the net and discharged from the fine stuff portal by the centrifugal force and cyclone propelling power, which are caused by the rotor vane inside the net tube. Other materials which cannot cross the net, are discharged from the rough stuff portal along the net tube wall.
Features of Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
1. The machine can operate either in a single unit or multiple units, and it is safe and reliable for a long time operation.
2. The new type roller bearing can prolong the service life.
3. The whole machine is in a small size and light so that it is stable in operation, free from vibration and noise, and with its good sealed structure, it is free from dust and performs in high efficiency.
4. The machine can work with the pneumatic conveying systems, and materials can be directly sent into the wind path to save resources.
5. It will form the air-isolated layer to avoid the powder entering the bearing so as to prolong the service life of the bearing effectively, reduce the maintenance frequency, and increase work efficiency.
6. The screen-mesh can be cleaned automatically by cyclone.
7. The machine can be specially designed to meet special requirements.
8. The shell of machine is in a new design which makes it easy to install and convenient to control.
9. The machine has the function of re-crashing the agglomeration materials.
10. New design: The airflow protection system can transfer the purified air to the two ends of the device, which will reduce the temperature created in the operation of the device.
Important Information You May Care About Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
| Name | centrifugal sifter, rotary sifter, airflow screen, turbo sieve etc. |
| Model | AL-18-65, AL-30-100, AL-50-130 (special model can be customized) |
| Screen Size | screen diameter*length 180mm*650mm, 300mm*1000mm, 500mm*1300mm |
| Motion | rotary motion |
| Mesh Deblinding System | De-blinding with air, rubber, brush etc. |
| Machine Material | stainless steel 304, Q235A etc. |
| Mesh Material | stainless steel woven wire mesh, nylon mesh, wedge screen etc. |
| Layers of Screen | single layer of screen |
| Mesh Size | below 500 mesh |
| Purpose | for sieving materials of sticky, static and multi-fiber etc. |
| Application | calcium carbonate, diatomite, silica sand, quartz powder, diatomite, white cement, battery material, starch, chili powder, glucose powder, herbal powder etc. |
General Type Cantilever Type
Stainless Steel Woven Wire Mesh Nylon Mesh
Overall Dimensions of Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
| Model | A | B | C | D | E | F | G | H | I | J |
| AL-18-65 | 1430 | 460 | 420 | 1005 | 135 | 230 | 250 | 330 | 340 | 210 |
| AL-30-100 | 1845 | 655 | 766 | 1240 | 320 | 285 | 300 | 350 | 380 | 290 |
| AL-50-130 | 2230 | 870 | 790 | 1775 | 280 | 515 | 150 | 660 | 400 | 485 |
Note: we can design and manufacture special type of sieving machine according to user's requirement.
Technical Parameters of Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
| Model | Material | Apply to |
| AL-18-65 | Q235A, SUS304 | < 500 mesh |
| AL-30-100 | Q235A, SUS304 | < 500 mesh |
| AL-50-130 | Q235A, SUS304 | < 500 mesh |
Application of Horizontal Airflow Centrifugal Rotary Sifter Screen for Vital Wheat Gluten:
The rotary centrifugal sifter is especially suitable for grinding plant powder, such as:
Chinese herbal medicine powder;
Spices: curry powder, ginger powder, garlic powder, chili powder, pepper powder material etc.
Cosmetics, mica powder, pearl pigment superfine powder and so on.
