| Place of Origin: | China |
| Brand Name: | AAREAL |
| Certification: | ISO9001:2015 |
| Model Number: | APQ |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Fumigation-free plywood wooden case for small size parts, and plastic film for big size device |
| Delivery Time: | 15~35 work days after order confirmed |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 5 sets per month |
| Features: | Small Size, High Screening Accuracy, Low Failure Rate And Convenient Maintenance. | Layers Of Screen: | Single Layer Of Screen |
|---|---|---|---|
| Optional Device: | Ultrasonic System, Pulse Dust Collector Etc. | Type: | High-performance Blow-through Type Air Classifier Screen Machine |
| Advantage: | Can Sift Particles That The Ultrasonic Separator Can Not Manage | Anti-blocking: | No Blockage Because Of The Air Brush |
| Application: | Particles With Static Electricity, Materials Easy To Agglomerate And With Light Specific Gravity, Viscous Materials Containing Water Or Oil Etc. | Material To Be Processed: | Spherical Graphite, Talcum Powder Etc. |
| High Light: | Vortex Airflow Rotary Sifter Screens,325 Mesh Rotary Sifter Screens,Graphite Powder Rotary Sifter Screens |
||
Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder
Overview of Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder:
Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder is also called vortex screen, air classifier, airflow screen machine, high efficiency wind screening machine, blow-through type high-performance sieving machine etc. It provides continuous dry material screening, achieving the high efficiency micron-sized accurate separation of 25µm~8500µm particles.
It is suitable for materials that are difficult to screen with traditional equipments such as vibrating screen, ultrasonic screening machine, tumbler screen etc.. For example, particles with static electricity, materials easy to agglomerate and with light specific gravity, viscous materials containing water or oil and so on. Or it can be used behind the airflow classifier to ensure that the ultra-fine powder is without large particles after the classifier.
Application of Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder:
The blow-through type high-performance vortex sieving machine can be used in food, powder metal, chemical, plastic, cosmetics, pigments, tobacco, pharmaceuticals, minerals, electronics, ceramics and other industries. Such as graphite powder, carbon powder, wood flour, soldering tin, talcum powder, powder coating, toner etc.
| Material | Soldering Tin | Talcum Powder | Powder Coating | Toner | Carbon Powder | Wood Flour | |
| Capacity | APQ-18 | 30 | 100 | 50 | 70 | 50 | 70 |
| APQ-30 | 120 | 420 | 200 | 420 | 200 | 300 | |
| Screen Mesh (µm) | 25 | 75 | 75 | 45 | 75 | 150 | |
Working Principle of Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder:
Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder ontrols the particle size precisely through the screen mesh.
The powder is dispersed in the airflow and through the static screen, so it can accurately screen micron-sized powder, which can not be realized by vibration type sieving machine or air classifier.
The blow-through type high-performance vortex sieving machine has a great contribution to the diversification, high added value and high quality of all kinds of powder raw materials and products. Furthermore, for the powder with humidity, oil content and electric charge that is difficult to screen and yield can not be guaranteed, it is a professional screening machine.
Features of Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder:
1. There is no blockage because of the air brush. Thus the vortex screen can sieve smoothly from the granular to the micro powder, and finally to several microns of ultrafine particles.
2. Fully automatic continuous operation. It can be easily added into the grinding and pneumatic conveying production line.
3. It takes just a few minutes to realize quick screen replacement.
4. With unique working principle and excellent screen anti-blocking performance, it is almost allowed to screen any type of powders regardless of the specific gravity size, and no matter whether it has the powder properties such as adhesiveness, cohesion, coagulation, fluidity, hygroscopicity and so on, more suitable for screening lightweight and electrostatic materials. It can easily complete the spherical particle sieving that the ultrasonic screening machine can not manage.
5. Cover a small area. The processing capacity per unit area of screen is super strong.
6. Slight vibration, low noise, full closed structure, no dust, no pollution.
7. High screening accuracy, low failure rate and convenient maintenance.
Technical Parameters of Ultrasonic Vortex Airflow Screen Machine for 325 Mesh Spherical Graphite Powder:
| Model | Screen Diameter (mm) | Power (KW) | Weight (KG) |
| APQ-18 | 458 (18 inches) | 4 | 230 |
| APQ-30 | 762 (30 inches) | 5.5 | 560 |
| APQ-38 | 965 (38 inches) | 7.5 | 650 |
| APQ-45 | 1145 (45 inches) | 11 | 820 |
