Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AL
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 15~35 work days after order confirmed
Payment Terms: T/T, L/C
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Other Names: Airflow Screen, Centrifugal Sifter, Rotary Screen, Rotary Sifter Etc. Purpose: For Sieving Materials Of Sticky, Static And Multi-fiber
Movement: Rotary Motion Layers Of Screen: Single Layer Of Screen
Mesh Material: Stainless Steel Woven Wire Mesh, Nylon Mesh Screen Etc. Sieve Drum Size: Diameter*length 180*650mm, 300*1000mm, 500*1300mm Etc.
Mesh Size: Below 500 Mesh Application: White Cement, Calcium Carbonate, Diatomite, Battery Material, Starch, Glucose Powder Etc.
High Light:

air classifier machine

,

rotary sifter machine



Horizontal Rotary Sifter Screens Air Flow Centrifugal Sifter Screens Single Layer



Introduction of Horizontal Air Flow Centrifugal Sifter for Heavy Calcium Carbonate:

The Horizontal Air Flow Centrifugal Sifter for Heavy Calcium Carbonate is also called airflow screen, centrifugal sifter, centrifugal sieve, airflow sieve, horizontal airflow screen, turbo sieve, cyclone sieve, airflow centrifugal sifter, centrifugal screener, centrifugal powder sifter, rotary screen, rotary sieve, rotary sifter, air classifier etc.

  The centrifugal sifter is a kind of screening machine making use of centrifugal force and cyclone for material separation. It is available with a cylindrical sieving chamber in which there are helical paddles supporting rotation motion. Screw conveyor is employed for material feeding. While propelling the feeding material against the screen,the rotating paddles also create centrifugal force and cyclone which accelerates the particles through the apertures. The centrifugal screen is designed with two outlets. Fine materials that can pass through the screen mesh are discharged via the fine material outlet, while others that can not pass through the screen are discharged from the coarse material outlet along the wall of the screen cylinder.



Working Principle of Horizontal Air Flow Centrifugal Sifter for Heavy Calcium Carbonate:

  The rotary sifter is a cylindrical screen, placing in the body, material through the screw conveyor system, then mixing and atomization with the air going into the mesh tube; material was forced to spray over the screen mesh due to centrifugal force and cyclone propulsion coming out from the blade of wind turbine in the screen mesh tube synchronous, and discharge by fine material outlet; the material that can’t be over the screen mesh is discharged by coarse material outlet along the wall of the tube.



Features of Horizontal Air Flow Centrifugal Sifter for Heavy Calcium Carbonate:

1. Small size of the whole machine, light in weight, stable and no vibration, no noise, good sealing performance, no dust, high efficiency;
2. Using with single or multi-machine matching, continuous operation of long time, safe and reliable;
3. Novel shell structure, simple installation, convenient to control;
4. New outer spherical bearing, prolonging service life;
5. Scouring the screen by cyclone, automatic mesh cleaning; re-crushing function of the agglomerate material;
6. The machine can be matched with pneumatic conveying system, and directly string into the wind road to conserve energy;
7. Novel design: gas protection system will purified air to the equipment at both ends so that effectively reduce the temperature produced in the operation process;
8. Gas barrier layer is formed on the bearing to prevent dust entering, so that can effectively prolong the service life of the bearing, reduce maintenance frequency, and improve work efficiency; it can be specially designed to meet the special needs.

Horizontal Rotary Sifter Screens Air Flow Centrifugal Sifter Screens Single Layer 0

Technical Parameters of Horizontal Air Flow Centrifugal Sifter for Heavy Calcium Carbonate:

Model Material Apply to
AL-18-65 Q235A, SUS304 < 500 mesh
AL-30-100 Q235A, SUS304 < 500 mesh
AL-50-130 Q235A, SUS304 < 500 mesh



Horizontal Rotary Sifter Screens Air Flow Centrifugal Sifter Screens Single Layer 1

Overall Dimensions of Horizontal Air Flow Centrifugal Sifter for Heavy Calcium Carbonate:

Model A B C D E F G H I J
AL-18-65 1430 460 420 1005 135 230 250 330 340 210
AL-30-100 1845 655 766 1240 320 285 300 350 380 290
AL-50-130 2230 870 790 1775 280 515 150 660 400 485

Note: we can design and manufacture special type of sieving machine according to user's requirement.



Horizontal Rotary Sifter Screens Air Flow Centrifugal Sifter Screens Single Layer 2 Horizontal Rotary Sifter Screens Air Flow Centrifugal Sifter Screens Single Layer 3

                         General Type                                                          Cantilever Type



Horizontal Rotary Sifter Screens Air Flow Centrifugal Sifter Screens Single Layer 4 Horizontal Rotary Sifter Screens Air Flow Centrifugal Sifter Screens Single Layer 5

               Stainless Steel Screen                                                         Nylon Screen



Application of Horizontal Air Flow Centrifugal Sifter for Heavy Calcium Carbonate:

  The horizontal airflow rotary screen can be widely used for sieving materials of sticky, static and multi-fiber. Applicable to metallurgy, mining, pharmaceutical, food, chemical, metal powder and non-metal industries etc.

  For example, Chinese medicine powder, battery material, starch, glucose powder, xylitol, soybean protein, peanut protein, vitamin C, sorbitol, ganoderma lucidum powder, malt powder, coffee powder, bread powder, flour, condiments, food additives, traditional Chinese medicine powder, APIs, pharmaceutical raw materials, active pharmaceutical ingredients, pharmaceutical intermediates, glass beads, perlite, silicon carbide, silicon powder, activated carbon, epoxy resin, polyethylene powder, fire extinguishing agent, zircon powder, pigment (phthalocyanin blue, phthalocyanin red, phthalocyanin yellow, yellow lead, high sand ceramic pigments etc.), magnetic material, drill powder, pyrophyllite powder, barium sulfate, lithium manganese oxide, zinc borate, coal ash, silicon powder, glaze, powder coating, pollen, dehydrated vegetable, egg powder, milk powder, soda powder, essence, magnesium oxide, magnesium hydroxide, calcium oxide, silicon nitride, alumina, molybdenum disulfide, cellulose, nanograde titanium dioxide, PVC resin powder, barium sulfate, silica gel powder, guar bean gum, calcium fluoride and other powder materials.
