Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AY
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Diameter: 400, 600, 800, 1000, 1200, 1500, 1800, 2000mm Grade: General Grade, Food Grade, Pharmaceutical Grade Etc.
Surface Finish: Paint, Sandblast, Mirror Finish Etc. Layers Of Screen: 1~5 (recommend 1~3)
Screen Material: Stainless Steel, Nylon, Polyurethane, Plastic Etc. Sieve Type: Woven Wire Mesh, Perforated Plate, Grizzly Bar Etc.
Mesh Cleaning System: Ultrasonic, Bounce Balls, Rotary Brush System Etc. Application: Quick Lime, Calcium Carbonate, Kaolin, Wood Powder, Quartz Sand Etc.
High Light:

CaO Vibro Sieve Machine

,

800mm Vibro Sieve Machine

,

CaO vibro sieve separator

High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading



Introduction of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading is designed for generic separation. It is suitable for wet and dry, grading, classification, de-dusting, and quality control. The multi-purpose model is essential to improve quality and safety of production materials, increase productivity, and reduce cost and labour.
  Continuous development along with various available add-ons, makes the LS basic model a versatile unit capable of separation up to 6 grades (5 layers of screens).



Some Information About High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

Model AY
Shape round shape
Layers of Screen 1~5 screen decks with 2~6 discharge ports
Mesh Size above 325 mesh
Screen Frame adhesive type, L type (bolt insert type), ultrasonic type (transducer internal and external), flange type etc.
Self-cleaning System bouncing balls (with ball decks, rubber balls, silicone balls etc.), ultrasonic de-blinding system, rotary brush system etc.
Diameter 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm etc.
Material stainless steel 304, 316L, carbon steel, plastic materials etc.
Surface Treatment Paint, sandblast and mirror polish etc.
Function solid-separation, grading, remove the impurity etc.
Movement three dimensional vibration motion
Damping Spring carbon steel spring, stainless steel spring, air spring, rubber spring etc.
Motor one set of vibrating motor, verticle arrangement (sufficient power)
Motor Brand AAREAL Made, OLI-WOLONG, Italvibras etc.
APO Safety System Automatic Power Off Safety System is integrated in the motor
Quick-wear Parts

mesh screen, perforated plate, bounce balls, clamps, springs,

sealing rubber strip, vibrating motor etc.

Optional Design discharge gate, magnetic guard, quick release clamp, glass viewing port, collecting tray etc.
Work Level general grade, food grade, pharmaceutical grade etc.



Structure of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 0

  The rotary vibro sieve is composed of a upper cover, a screen box, a base and a vertical motor with eccentric weight installed at two ends. Our rotary vibrating screen machine can be produced in horizontal, vertical, inclined motions by adjusting the upper and lower eccentric weight. Diameter also can be ranged from 400mm to 2000mm, with single or multiple screening decks, material can be total carbon steel, total stainless steel or material contact parts are stainless steel according to different product.



Purpose of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 1High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 2High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 3

                   Grading                        Solid-liquid Separation                    Impurity Removal



1. Classification: Granules/powder accurate classification
2. Filtration: Remove granules foreign matter in the liquid
3. Removal impurity: Remove the foreign matter or agglomerate



Working Principle of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 4

  The vibration is accomplished by eccentric weights on the upper and lower ends of the motion-generator shaft. The direction of the eccentric weights can change its rotational mode,rotation of the upper weight creates vibration in the horizontal plane, which causes material to move across the screen cloth to the periphery,while the lower weight acts to tilt the machine, causing vibration in the vertical and tangential planes. The trajectories of materials on the screen can be changed by adjusting the phase angle of upper and lower weights.

High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 5

High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 6



Characteristics of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

1. Light weight - easily movable with pellet jack or forklift.

2. Simple and functional design – higher capacity, easy use, less maintenance, lower noise, and require minimal floor space.
3. Highly durable - designed for long hours of operation with minimal service required.

4. Wide range of sizes and modifications available to suit all types of powder and viscous liquids.

5. Quick change design - allows screen change in less than 5 minutes.
6. Stainless Steel - all contact parts in stainless steel SS304. Full or partial SS316L upgrades available.

7. Anti-binding devices - prevent screen clog without creating dust clouds during operations.
8. Automatic discharge of separated materials - continuous and uninterrupted production.
9. Up to 5 screens per unit - allowing multiple separations with just one unit for cost effective operation.

10. Lower energy consumption - reduce cost.



Overall Dimensions of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 7

Model A B C D E F G I Single Layer Height Double Layer Height

Three

Layer

Height

AY-400 472 372 150 400 110 60 300 270 550 660 770
AY-600 570 450 200 600 120 80 380 340 730 865 1000
AY-800 690 570 200 800 130 100 550 340 730 865 1000
AY-1000 810 690 250 970 150 120 650 400 790 925 1060
AY-1200 970 850 250 1170 180 130 760 450 860 1025 1190
AY-1500 1180 1060 250 1470 200 140 950 480 985 1180 1370
AY-1800 1480 1360 350 1770 220 150 1110 520 1030 1220 1410



Technical Parameters of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

Model Power Screen Surface Diameter Effective Screen Area (sqm) Decks
AY-400 0.18 KW 350mm 0.0962 1~3
AY-600 0.25 KW 550mm 0.2375 1~3
AY-800 0.55 KW 750mm 0.4416 1~3
AY-1000 0.75 KW 920mm 0.6644 1~3
AY-1200 1.1 KW 1120mm 0.9847 1~3
AY-1500 1.5 KW 1420mm 1.5829 1~3
AY-1800 2.2 KW 1720mm 2.3223 1~3
AY-2000 3.0 KW 1920mm 2.89 1~3

 Note: our company reserve the right to modify the above data.



Application of High Capacity Rotary Vibrating Sieve Machine for CaO Quick Lime Grading:

1. Food industry: Sugar powder, starch, egg powder, sauce, salt, rice noodles, milk powder, soybean milk, syrup, etc.

2. Chemical industry: PVC powder, resin, pigment, rubber, industrial medicine, cosmetic, coatings, etc.
3. Metal, metallurgy and mining industry: Aluminum powder, ceruse, copper powder, ore alloy powder, welding rod powder, electrolysis copper powder, electromagnetism materials, manganese dioxide, grinding powder, fire-resistant material, lime, heavy calcium carbonate, alumina, etc.
4. Pharmacy profession: western medicine powder, liquid, Chinese herbal medicine, particle, etc.

5. Social pollution disposed: Disposed oil, disposed water, disposed dye water, assistant, active carbon.
6. Ceramic and abrasive: Alumina, quartz sand, mud etc.
7. Paper making: Paper pulp, paint, wasted water recycling.



High Capacity Vibro Sieve Machine Round Separator For CaO Quick Lime Grading 8
