Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material

  • Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material
  • Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material
Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AY
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Function: Grading, Solid-liquid Separation, Impurity Removal Etc. Feature: Small Size, Multi-layer, High Screening Accuracy Etc.
Model: AY-600, 800, 1000, 1200, 1500, 1800, 2000 Mesh Cleaning System: Rubber Balls, Ultrasonic System, Rotary Brush System Etc.
Layers Of Screen: 1~5 Layers (suggest 1~3 Layers) Screen Material: Stainless Steel, Polyurethane, Nylon Etc.
Voltage: Three Phase, 380V, 50HZ (customizable) Motor: Verticle Vibrating Motor, Excitation Force And Amplitude Adjustable
High Light:

vibrating sieve screen

,

vibratory screen separator

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material



Introduction of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice is a high-precision fine powder screening machine with low noise and high efficiency. It is also named as Rotary Vibrating Screen, rotary vibrating sieve, vibro screen, vibro sifter, gyro screen etc.. It is specially designed as a high precision screening machinery. Rotary vibrating sieve is suitable for screening granular, powdery, Liquid material.



Structure Diagram of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 0

Working Principle of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 1

1. The three-dimensional vibrating screen is made up of an upright motor as an excitation source. The upper and lower ends of the motor are equipped with an eccentric weight to convert the rotary motion of the motor into a horizontal, vertical, and inclined three-dimensional motion, and then transmit this motion to The sieve surface makes the material expand and involute on the screen surface, so the series of vibrating screens is called a vibrating screen.



2. The vibrating screen has the advantages of long track of material running and high utilization rate of screen surface. Adjusting the phase angle of the upper and lower ends of the hammer can change the movement track of the material on the screen surface. The material can be finely sieved and probability sieved.



3. After the vibrating screen is started, the power device is the eccentric block with different phases at the upper and lower ends of the vibrating motor. Due to the high-speed placement, a compound inertial force is generated, which forces the vibrating body of the screen to perform the reciprocating motion, and the screen frame is vibrating.



4. Under the action of the continuous reciprocating motion, the ground is driven to drive the screen surface for periodic vibration, so that the material on the screen surface is directionalally moved together with the screen box, during which the material smaller than the sieve surface diameter falls through the sieve hole to the lower layer, to become a sieve under the material, the material larger than the sieve aperture is discharged from the discharge opening after continuous jumping movement, and finally the screening work is completed.



5. The trajectory of the vibrating body of the vibrating screen is a complex spatial three-dimensional curve. The projection of the curve on the horizontal plane is circular, and the projections on the two vertical planes are two identical ellipse. In practical application, by adjusting the relative phase of the eccentric block at the upper and lower ends of the vibration motor, the movement trajectory of the material on the sieve surface can be changed, thereby achieving different screening operations.



Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 2

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 3



Some Information About Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Model AY
Shape circular or round shape
Layers of Screen 1~5 layers of screen with 2~6 outlets
Mesh Size above 325 mesh
Screen Frame adhesive type, L type (bolt insert type), ultrasonic type (transducer internal and external) etc.
Self-cleaning System bouncing balls (with ball decks), ultrasonic de-blinding system, rotary brush system etc.
Diameter 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm
Material stainless steel 304, 316L, carbon steel, plastic materials etc.
Surface Treatment Paint, sandblast and polish etc.
Function solid-separation, grading, remove the impurity etc.
Movement three dimensional vibration motion
Damping Spring carbon steel spring, stainless steel spring, air spring, rubber spring etc.
Motor one set of vibrating motor, verticle arrangement
Motor Brand OLI-WOLONG, Italvibras, AAREAL Made etc.
APO Safety System Automatic Power Off Safety System is integrated in the motor
Quick-wear Parts

mesh screen, perforated plate, bounce balls, clamps, springs,

sealing rubber strip etc.

Optional Design discharge gate, magnetic guard, quick release clamp, glass viewing port etc.



Purpose of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 4Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 5Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 6

1. Grading
Each model of circular vibrating sifter can precisely and continuously screen and separate screened products, the multi-layer type can sift and separate five groups of different particles at a time. It is suitable for dry materials.



2. Solid-liquid separation
The mixture of solid and liquid can be separated effectively by single or multi-layer type into different grade materials.



3. Remove the impurity
The rotary vibro sieve can quickly separate a few oversize or undersized particles from a quantity of materials.



Features​ of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

1. Anti-binding devices - prevent screen clog without creating dust clouds during operations.
2. Automatic discharge of separated materials - continuous and uninterrupted production.

3. Simple and functional design - higher capacity, easy use, less maintenance, lower noise, and require minimal floor space.
4. Lower energy consumption - reduce cost.
5. Light weight - easily movable with pellet jack or forklift.
6. Highly durable - designed for long hours of operation with minimal service required.
7. Stainless Steel - all contact parts in stainless steel 304. Full or partial stainless steel 316L upgrades available.
8. Wide range of sizes and modifications available to suit all types of powder and viscous liquids.
9. Up to 5 screens per unit - allowing multiple separations with just one unit for cost effective operation.
10. Quick change design - allows screen change in less than 5 minutes.



Overall Dimensions of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 7

Model A B C D E F G I Single Layer Height Double Layer Height

Three

Layer

Height

AY-400 472 372 150 400 110 60 300 270 550 660 770
AY-600 570 450 200 600 120 80 380 340 730 865 1000
AY-800 690 570 200 800 130 100 550 340 730 865 1000
AY-1000 810 690 250 970 150 120 650 400 790 925 1060
AY-1200 970 850 250 1170 180 130 760 450 860 1025 1190
AY-1500 1180 1060 250 1470 200 140 950 480 985 1180 1370
AY-1800 1480 1360 350 1770 220 150 1110 520 1030 1220 1410



Technical Parameters of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 8

Model Power Screen Surface Diameter Effective Screening Area (m2) Layers of Screen
AY-400 0.18 KW 350mm 0.0962 1~3
AY-600 0.25 KW 550mm 0.2375 1~3
AY-800 0.55 KW 750mm 0.4416 1~3
AY-1000 0.75 KW 920mm 0.6644 1~3
AY-1200 1.1 KW 1120mm 0.9847 1~3
AY-1500 1.5 KW 1420mm 1.5829 1~3
AY-1800 2.2 KW 1720mm 2.3223 1~3
AY-2000 3.0 KW 1920mm 2.89 1~3



Application of Stainless Steel Rotary Vibrating Filter Sieving Machine for Spice:

Food industry: Sugar powder, starch, salt, rice powder, milk powder, soy milk, egg powder, soy sauce, fruit juice, tea, beverage, dairy, candy, small food, frozen food, seasoning, protein, food additives, etc
Chemical industry: Resins, coatings, industrial chemicals, cosmetics, paints, etc.
Metallurgical powder industry: Aluminum powder, lead powder, copper powder, ore, alloy powder, electrode powder, manganese dioxide, electrolytic copper powder, electromagnetic material, abrasive powder, refractory material, kaolin, lime, alumina, heavy calcium carbonate, quartz sand, etc.
Other industry: Waste oil, wastewater, dyeing and finishing wastewater, paper making, additives, activated carbon, Chinese medicine powder, granule pills, pellets, etc.



Spice Vibrating Screen Machine Tumbler Sifter Stainless Steel Material 9
