High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor

High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor

  • High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor
  • High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor
High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor
Product Details:
Place of Origin: China
Brand Name: AAREAL
Certification: ISO9001:2015
Model Number: AY
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Fumigation-free plywood wooden case for export
Delivery Time: 20~30 work days after order confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Other Names: Vibrating Sifter, Vibrating Shifter, Round Separator, Rotary Vibrating Screen, Rotary Vibrating Sieve, Vibro Screen Etc. Motion: Three Dimensional Movement
Perpose: Particle Size Grading, Impurity Removal, Filtering, De-watering, De-dusting, Lump Breaking, Cooling, Size Control Etc. Drive Device: Verticle Vibrating Motor
Screen Frame: Bolt Insert Type, Adhesive Type, Flange Type, Ultrasonic Type (internal And External Transducer) Etc. Mesh Cleaning Method: Bouncing Rubber Balls, Ultrasonic Deblinding Device, Rotary Brush System Etc.
Optional Parts: Quick Release Clamp, Magnetic Guard, Discharge Gate, Glass Viewing Port Etc. Other Design: Low-profile Design, Double Motor Structure, Avalanche Design, High Frequency Design Etc.
High Light:

round vibrating screen

,

round separator



High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor



Overview of Rotary Vibrating Screen Separator Machine For Cosmetics​:

The rotary vibrating screen separator machine for cosmetics is known as the rotary vibrating screen, rotary vibrating sieve, round separator, vibro screen, vibrating sifter, round vibro sieve, gyro screen, gyro sieve, round sifter, round screener, round vibro sieve machine, round gyratory screen, rotary screen, rotatory vibrating screen, rotary vibrating sieve, circular vibratory screen, circular vibrating screen, circular vibrating sieve, gyro screen, gyro sifter, gyratory sifter, gyratory screen, gyratory sieving machine, vibro sifter, vibro separator, vibro grader, classic separator, vibratory separator, vibratory sifter, sanitary separators, filter sieve machine, industrial sifter etc.

  The rotary vibrating screen separator machine uses vibration motor as the source of vibration,equipped eccentric hammer on the both sides of motor,the rotation of hammers change circumrotate to level ,upright and incline movement,then pass these three movement to surface of the screen mesh. Adjust the phasic angle of the top hammer and bottom hammer to change the movement track of the material. This will help to screen different materiel in different situation successfully.



Important Information You May Concern About Rotary Vibrating Screen Separator Machine For Cosmetics:

Model AY
Shape round
Layers of Screen 1~5 screen decks
Mesh Size above 325 mesh
Screen Frame L type, adhesive type, ultrasonic type (transducer internal and external) etc.
Mesh Cleaning Method bouncing balls, ultrasonic system, rotary brush system etc.
Diameter 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm
Material carbon steel, stainless steel 304, 316L etc.
Function grading, solid-separation, remove the impurity etc.
Movement three dimensional vibration motion
Damping Spring galvanized steel spring etc.
Motor verticle vibrating motor
Motor Brand China Made, OLI-WOLONG etc.
Optional quick release clamp, magnetic guard, discharge gate, glass viewing port etc.



Screen Frame Or Screen Holder Optional:

High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor 0



High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor 1

Working Principle of Rotary Vibrating Screen Separator Machine For Cosmetics:

  The multi-deck rotary vibating screen separator adopts the latest vertical vibrating motor, which produces a horizontal, vertical and oblique vibration of three dimensional, and then directly passes the vibration to screen surface. Changing the angle of the upper and lower eccentric block of the motor, it produces different exciting force, and the direction in which the material is running is changed.

  The round vibrating separator is a vibratory screening device that vibrates about its center of mass. The vibration is accomplished by eccentric weights on the upper and lower ends of the motion-generator shaft. The rotation of the top weight creates vibration in the horizontal plane, which causes material to move across the screen cloth to the periphery. The lower weight acts to tilt the machine, causing vibration in the vertical and tangential planes. The angle of lead given the lower weight with relation to the upper weight provides variable control of the spiral screening pattern. The speed and spiral pattern of material travel over the screen cloth can be set by the operator for maximum throughput and screening efficiency of any screenable products: wet and dry, heavy and light, coarse and fine, hot and cold and so on.

High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor 2

  The general characteristics of the vibrator adjustment are described below:

High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor 3



Structure Diagram of Rotary Vibrating Screen Separator Machine For Cosmetics:

High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor 4

Features of Rotary Vibrating Screen Separator Machine For Cosmetics:

1. The screening accuracy exceeds 90%.
2. It adopts whole sealing structure design,the sealed effect is fairly well, no dust pollution, no leaking liquid, no material left in machine, and no dead angle in the net frame.
3. Small volume and light weight,easy to be installed and maintained.
4. The outlet can be adjusted at any angle,and it is easy to change the screen.
5. The rubber ball device can reduce the chance of jam on the screen.
6. By adding the Ultrasonic Instrument Conversion device, superfine materials up to 600 mesh can be sieved.
7. Self cleaning device: silicone ball, rotary silicone brush, ultrasonic device and pneumatic device.
8. Automatic feeding system
9. Transparent plastic cover or sight glass window .
10. Round separator in other designs are also available such as low profile design, double motor structure, avalanche design, high frequency design etc.



Basic Function of Rotary Vibrating Screen Separator Machine For Cosmetics:

High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor 5

1. Grading
Each model of vibrating sieve machine can precisely and continuously screen and separate screened products, the multi-layer type can screen and separate five groups of different particles at a time. It is suitable for dry materials.



2. Solid-liquid separation
The mixture of solid and liquid can be separated effectively by single or multi-layer type into different grade materials.



3. Remove the impurity
The model can quickly separate a few oversize or undersized particles from a quantity of materials.



Technical Parameters of Rotary Vibrating Screen Separator Machine For Cosmetics:

Model Power Screen Surface Diameter Effective Screening Area (m2) Layers
AY-400 0.18 KW 350mm 0.0962 1~3
AY-600 0.25 KW 550mm 0.2375 1~3
AY-800 0.55 KW 750mm 0.4416 1~3
AY-1000 0.75 KW 920mm 0.6644 1~3
AY-1200 1.1 KW 1120mm 0.9847 1~3
AY-1500 1.5 KW 1420mm 1.5829 1~3
AY-1800 2.2 KW 1720mm 2.3223 1~3
AY-2000 3.0 KW 1920mm 2.89 1~3

High Accuracy Rotary Vibrating Screen Separator Machine Vertical Type Motor 6

Overall Dimensions of Rotary Vibrating Screen Separator Machine For Cosmetics:

Model A B C D E F G I Single Layer Height Double Layer Height

Three

Layer

Height

AY-400 472 372 150 400 110 60 300 270 550 660 770
AY-600 570 450 200 600 120 80 380 340 730 865 1000
AY-800 690 570 200 800 130 100 550 340 730 865 1000
AY-1000 810 690 250 970 150 120 650 400 790 925 1060
AY-1200 970 850 250 1170 180 130 760 450 860 1025 1190
AY-1500 1180 1060 250 1470 200 140 950 480 985 1180 1370
AY-1800 1480 1360 350 1770 220 150 1110 520 1030 1220 1410



Application of Rotary Vibrating Screen Separator Machine For Cosmetics:

1. Chemical Industry: colophony, industry leechdom, cosmetic, paint.
2. Grinding Materials And china Industry: alumina, quartz, slurry, kaoline, carborundum, sprayer dust.
3. Food Industry: sugar,flour,amylum, rice powder,milk powder, soyabean milk, angel cake,juice,sauce,spice,salt,starch.
4. Paper-Making Industry: dope,white soil slurry, black and white liquid, disposed liquid, paper-making liquid and waste water recycling.
5. Metallurgy, Mining Industry: aluminum powder, ceruse, copper powder, ore alloy powder, welding rod powder, dioxide manganese, electrolyze copper powder, electromagnetic material, rubbing powder, fire-proof material, kaoline, lime, heavy calcium carbonate.
6. Pharmacy Industry: chinese herbal medicine liquid, medicine powder, liquid and particle.
