| Place of Origin: | China |
| Brand Name: | AAREAL |
| Certification: | ISO9001:2015 |
| Model Number: | AM |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Fumigation-free plywood wooden case for export |
| Delivery Time: | 20~35 work days after order confirmed |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 5 sets per month |
| Screening Accuracy: | High Up To 90% ~ 99.9% | Motion: | Tumbling Motion |
|---|---|---|---|
| Other Names: | Tumbler Screener, Tumbler Screening Machine, Tumbler Screen, Tumbling Screen | Mesh Cleaning Method: | Ultrasonic System, Self-cleaning Ball System, Rolling Brush, Air Brush Etc. |
| Diameter: | 600mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm Etc. | Layers Of Screen: | 1~5 Layers |
| Optional Device: | Pneumatic Lifting Devices, Quick Clamps Etc. | Application: | Nickel Ore, Food Flour, Micronised Materials, Mineral Powders, Plastic Powders, Plastic Powder, Glass Beads, Xylitol, Citric Acid, Food Additives, Calcium Carbonate Etc. |
| High Light: | Nickel Ore Vibro Separator Machine,1800mm Vibro Separator Machine,Nickel Ore Vibrating Sieve Screen |
||
High Efficiency Vibro Separator Machine Nickel Ore Vibrating Sieve Screen
Overview of Tumbling Screening Machine for Nickel Ore:
Tumbling screening machine for nickel ore is an efficient sieving machine, which is designed to meet the large output and high-density sieving of the manufacturer. The tumbling screening machine is also known as tumbler screen, tumbler screener, tumbler screening machin, tumbler sieve, swinging sieve, shaking sieve etc.
The simplest screening is using your hands with the staring of your eyes. Tumbler screening is the mechanical simulation for the simplest one, it is the most effective method to stimulate the principle of artificial screen movement (screening accuracy, efficiency, life of screen mesh are 5 to 10 times than the common circular screen). It conforms to all range of fine and ultra-fine powder and particle materials, especially suitable for processing hard materials. It is typically used to sieve extremely ine and/or lightweight products, such as food flour, micronised materials, mineral powders, plastic powders etc.
We have several different models of the tumbler fine sieve. Each tumbler screening machine has its corresponding specifications that can vary depending on the manufacturer’s output and processing requirement. The unit also has a sealing structure which helps prevent any dust from going in or spilling out of the machine that might cause inconsistencies with the final output of the sieved material.
Important Information About Tumbling Screening Machine for Nickel Ore You May Care:
| Motion | involute spiral motion |
| Screening Accuracy | upto 90%~99.9% |
| Mesh Cleaning Method | bouncing ball cleaning, ultrasonic cleaning, brush cleaning, air cleaning, ultrasonic air cleaning, air brush cleaning |
| Screen Structure | whole adhesive screen, or splicing segmented screen etc. |
| Layers of Screen | 1~5 layers of screen |
| Diameter | 600mm, 1000mm, 1200mm, 1400mm, 1500mm, 1600mm, 1800mm, 2000mm, 2100mm, 2300mm, 2600mm etc. |
| Advantages | soft rock screening will not destroy the particles original structure of the material and not easy to produce static electricity |
| Optional | quick clamps, pneumatic lifting devices etc. |
| Application | can be used for material that is flammable, explosive and easy to generate static |
Features of Tumbling Screening Machine for Nickel Ore:
Working Principle of Tumbling Screening Machine for Nickel Ore:
The tumbler screen machine is an artificial imitation of shaking low frequency vibration sieve, working principle is synthesis of transient motion displacement and this displacement in the radial direction of the axis of circular motion (helical motion), can adjust the eccentricity nonlinear three-dimensional motion of the exciter, the material also produces same motion approximation manual jobs, so as to achieve the purpose of screening, combined with sieving attachment can get more ideal screening effect. Suitable for circular, cylindrical, sheet, and even regular shapes easy to block network and require sophisticated screening materials.
Technical Parameters of Tumbling Screening Machine for Nickel Ore:
| Model | Screen Area (m²) | Layers of Screen | Motor Power (KW) |
| AM-600 | 0.28 | 1~5 | 0.25 |
| AM-1000 | 0.72 | 1~5 | 1.5 |
| AM-1200 | 1.10 | 1~5 | 1.5 |
| AM-1500 | 1.80 | 1~5 | 2.2 |
| AM-1800 | 2.30 | 1~5 | 4.0 |
| AM-2000 | 2.60 | 1~5 | 4.0 |
| AM-2300 | 3.90 | 1~5 | 4.0 |
| AM-2600 | 5.30 | 1~5 | 5.5 |
| AM-2900 | 6.40 | 1~5 | 5.5 |
Application of Tumbling Screening Machine for Nickel Ore:
1. Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry etc.
2. Chemical industry: resin pigment, medicine, grease, paint, palette etc.
3. Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice etc.
4. Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide etc.
5. Mechanical industry: casting sand, powder metallurgy, electromagnetic material andmetal powder etc.
Pneumatic Lifting Device BALANCE IS IMPORTANT !!
